Specifications
 Page 42 
ID2-XY 105M+MC2-Y 105M
INDOOR
AIRFLOW
(CMH)
OUTDOOR
DB(℃)
ID WB
(℃)
16.0 18.0 19.0 22.0
ID DB
(℃)
23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0
1400
-15
TC 11.49 11.49 11.61 11.73 12.08 12.08 12.08 12.08 12.38 12.38 12.38 12.38 13.15 13.15 13.15 13.15
S/T 0.70 0.77 1.00 1.00 0.56 0.64 0.71 0.98 0.49 0.57 0.65 0.72 0.35 0.42 0.49 0.56
PI 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76
-10
TC 11.42 11.42 11.54 11.66 12.01 12.01 12.01 12.01 12.32 12.32 12.32 12.32 13.11 13.11 13.11 13.11
S/T 0.70 0.78 1.00 1.00 0.56 0.64 0.72 0.98 0.49 0.57 0.65 0.73 0.35 0.43 0.49 0.56
PI 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76
-5
TC 11.35 11.35 11.47 11.59 11.97 11.97 11.97 11.97 12.28 12.28 12.28 12.28 13.07 13.07 13.07 13.07
S/T 0.70 0.78 1.00 1.00 0.57 0.64 0.72 0.99 0.50 0.58 0.65 0.73 0.35 0.43 0.50 0.57
PI 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.76 2.77 2.77 2.77 2.77
0
TC 11.29 11.29 11.41 11.53 11.92 11.92 11.92 11.92 12.24 12.24 12.24 12.24 13.06 13.06 13.06 13.06
S/T 0.71 0.78 1.00 1.00 0.57 0.65 0.73 0.99 0.50 0.58 0.66 0.74 0.35 0.43 0.50 0.57
PI 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.77 2.78 2.78 2.78 2.78
5
TC 11.24 11.24 11.36 11.47 11.87 11.87 11.87 11.87 12.20 12.20 12.20 12.20 13.05 13.05 13.05 13.05
S/T 0.71 0.79 1.00 1.00 0.57 0.65 0.73 1.00 0.50 0.58 0.66 0.74 0.35 0.43 0.50 0.57
PI 2.79 2.79 2.79 2.79 2.79 2.79 2.79 2.79 2.79 2.79 2.79 2.79 2.80 2.80 2.80 2.80
10
TC 11.17 11.17 11.29 11.40 11.82 11.82 11.82 11.82 12.15 12.15 12.15 12.15 13.02 13.02 13.02 13.02
S/T 0.71 0.79 1.00 1.00 0.57 0.65 0.73 1.00 0.50 0.58 0.66 0.74 0.36 0.44 0.50 0.57
PI 2.84 2.84 2.84 2.84 2.83 2.83 2.83 2.83 2.83 2.83 2.83 2.83 2.83 2.83 2.83 2.83
15
TC 11.08 11.08 11.19 11.31 11.74 11.74 11.74 11.74 12.08 12.08 12.08 12.08 12.96 12.96 12.96 12.96
S/T 0.72 0.80 0.89 0.97 0.58 0.66 0.74 0.82 0.51 0.59 0.67 0.75 0.36 0.44 0.51 0.58
PI 2.91 2.91 2.91 2.91 2.90 2.90 2.90 2.90 2.89 2.89 2.89 2.89 2.89 2.89 2.89 2.89
20
TC 10.95 10.95 11.07 11.18 11.61 11.61 11.61 11.61 11.96 11.96 11.96 11.96 12.85 12.85 12.85 12.85
S/T 0.72 0.80 0.89 0.97 0.58 0.66 0.74 0.82 0.51 0.59 0.67 0.75 0.36 0.44 0.51 0.58
PI 3.01 3.01 3.01 3.01 3.00 3.00 3.00 3.00 2.99 2.99 2.99 2.99 2.98 2.98 2.98 2.98
25
TC 10.46 10.46 10.58 10.69 11.10 11.10 11.10 11.10 11.44 11.44 11.44 11.44 12.30 12.30 12.30 12.30
S/T 0.73 0.82 0.90 0.99 0.58 0.67 0.75 0.84 0.52 0.60 0.68 0.76 0.36 0.44 0.51 0.59
PI 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31 3.31
30
TC 9.98 9.98 10.06 10.18 10.61 10.61 10.61 10.61 10.92 10.92 10.92 10.92 11.76 11.76 11.76 11.76
S/T 0.74 0.83 0.92 1.00 0.59 0.68 0.76 0.85 0.52 0.60 0.69 0.78 0.36 0.44 0.52 0.60
PI 3.63 3.63 3.63 3.63 3.64 3.64 3.64 3.64 3.65 3.65 3.65 3.65 3.66 3.66 3.66 3.66
35
TC 9.46 9.46 9.54 9.63 10.06 10.06 10.06 10.06 10.38 10.38 10.55 10.38 11.21 11.21 11.21 11.21
S/T 0.75 0.85 0.94 1.00 0.59 0.69 0.78 0.87 0.52 0.61 0.70 0.79 0.35 0.44 0.52 0.60
PI 3.97 3.97 3.97 3.97 3.99 3.99 3.99 3.99 3.99 3.99 4.00 3.99 4.02 4.02 4.02 4.02
40
TC 8.91 8.95 9.04 9.12 9.49 9.49 9.49 9.53 9.79 9.79 9.89 9.79 10.60 10.60 10.60 10.60
S/T 0.77 0.88 0.99 1.00 0.60 0.71 0.81 0.91 0.53 0.62 0.72 0.82 0.35 0.44 0.53 0.90
PI 4.38 4.38 4.38 4.38 4.40 4.40 4.40 4.40 4.41 4.41 4.41 4.41 4.44 4.44 4.44 4.44
46
TC 8.25 8.34 8.42 8.51 8.80 8.80 8.80 8.88 9.09 9.09 9.09 9.09 9.86 9.86 9.86 9.86
S/T 0.78 0.89 1.00 1.00 0.61 0.72 0.82 0.93 0.53 0.63 0.74 0.84 0.34 0.44 0.53 0.92
PI 4.87 4.87 4.87 4.87 4.89 4.89 4.89 4.89 4.91 4.91 4.91 4.91 4.95 4.95 4.95 4.95
50
TC 7.73 7.82 7.91 7.99 8.28 8.28 8.28 8.37 8.57 8.57 8.57 8.57 9.29 9.29 9.29 9.29
S/T 0.80 0.92 1.00 1.00 0.62 0.73 0.85 0.95 0.53 0.64 0.75 0.86 0.34 0.44 0.54 0.97
PI 5.27 5.27 5.27 5.27 5.30 5.30 5.30 5.30 5.31 5.31 5.31 5.31 5.35 5.35 5.35 5.35
TC:Total Cooling Capacity (kW)
S/T:Sensible Cooling Capacity Ratio
PI:Power Input(kW)
Note: The table shows the case where the operation frequency of a compressor is fixed.
