CLIVET MC2-Y 105T Technical Manual

Specifications
 Page 48 
ID2-XY 140M+MC2-Y 140T
INDOOR
AIRFLOW
(CMH)
OUTDOOR
DB(℃)
ID WB
(℃)
16.0 18.0 19.0 22.0
ID DB
(℃)
23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0
2400
-15
TC 15.33 15.33 15.48 15.63 16.12 16.12 16.12 16.27 16.53 16.53 16.53 16.53 17.54 17.54 17.54 17.54
S/T 0.74 0.85 1.00 1.00 0.59 0.69 0.78 0.98 0.51 0.61 0.70 0.80 0.34 0.42 0.51 0.61
PI 3.57 3.57 3.57 3.57 3.56 3.56 3.56 3.56 3.56 3.56 3.56 3.56 3.55 3.55 3.55 3.55
-10
TC 15.23 15.23 15.38 15.53 16.03 16.03 16.03 16.18 16.45 16.45 16.45 16.45 17.48 17.48 17.48 17.48
S/T 0.75 0.85 1.00 1.00 0.59 0.69 0.79 0.98 0.51 0.61 0.71 0.81 0.34 0.43 0.51 0.61
PI 3.55 3.55 3.55 3.55 3.55 3.55 3.55 3.55 3.55 3.55 3.55 3.55 3.56 3.56 3.56 3.56
-5
TC 15.14 15.14 15.29 15.44 15.97 15.97 15.97 16.12 16.38 16.38 16.38 16.38 17.44 17.44 17.44 17.44
S/T 0.75 0.86 1.00 1.00 0.59 0.69 0.79 0.99 0.52 0.61 0.71 0.81 0.34 0.43 0.52 0.61
PI 3.55 3.55 3.55 3.55 3.54 3.54 3.54 3.54 3.55 3.55 3.55 3.55 3.56 3.56 3.56 3.56
0
TC 15.07 15.07 15.22 15.36 15.91 15.91 15.91 16.06 16.34 16.34 16.34 16.34 17.42 17.42 17.42 17.42
S/T 0.75 0.86 1.00 1.00 0.60 0.70 0.79 0.99 0.52 0.62 0.72 0.81 0.34 0.43 0.52 0.62
PI 3.56 3.56 3.56 3.56 3.56 3.56 3.56 3.56 3.57 3.57 3.57 3.57 3.57 3.57 3.57 3.57
5
TC 14.99 14.99 15.14 15.29 15.85 15.85 15.85 16.00 16.29 16.29 16.29 16.29 17.41 17.41 17.41 17.41
S/T 0.76 0.87 1.00 1.00 0.60 0.70 0.80 1.00 0.52 0.62 0.72 0.82 0.34 0.43 0.52 0.62
PI 3.59 3.59 3.59 3.59 3.59 3.59 3.59 3.59 3.60 3.60 3.60 3.60 3.60 3.60 3.60 3.60
10
TC 14.90 14.90 15.05 15.19 15.78 15.78 15.78 15.92 16.22 16.22 16.22 16.22 17.36 17.36 17.36 17.36
S/T 0.76 0.87 1.00 1.00 0.60 0.70 0.80 1.00 0.52 0.62 0.72 0.82 0.35 0.44 0.52 0.62
PI 3.66 3.66 3.66 3.66 3.64 3.64 3.64 3.64 3.65 3.65 3.65 3.65 3.65 3.65 3.65 3.65
15
TC 14.78 14.78 14.93 15.07 15.67 15.67 15.67 15.81 16.12 16.12 16.12 16.12 17.29 17.29 17.29 17.29
S/T 0.77 0.88 0.99 1.00 0.61 0.71 0.81 0.91 0.53 0.63 0.73 0.83 0.35 0.44 0.53 0.63
PI 3.74 3.74 3.74 3.74 3.73 3.73 3.73 3.73 3.73 3.73 3.73 3.73 3.72 3.72 3.72 3.72
20
TC 14.61 14.61 14.76 14.90 15.50 15.50 15.50 15.65 15.96 15.96 15.96 15.96 17.14 17.14 17.14 17.14
S/T 0.77 0.88 0.99 1.00 0.61 0.71 0.81 0.91 0.53 0.63 0.73 0.83 0.35 0.44 0.53 0.63
PI 3.87 3.87 3.87 3.87 3.86 3.86 3.86 3.86 3.86 3.86 3.86 3.86 3.84 3.84 3.84 3.84
25
TC 13.95 14.10 14.24 14.38 14.81 14.81 14.81 14.96 15.25 15.25 15.25 15.25 16.42 16.42 16.42 16.42
S/T 0.79 0.90 1.00 1.00 0.61 0.72 0.83 0.93 0.53 0.64 0.74 0.85 0.34 0.44 0.54 0.64
PI 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27 4.27
30
TC 13.29 13.44 13.58 13.72 14.13 14.13 14.13 14.27 14.56 14.56 14.56 14.56 15.68 15.68 15.68 15.68
S/T 0.80 0.92 1.00 1.00 0.62 0.73 0.85 0.96 0.53 0.64 0.76 0.87 0.34 0.44 0.54 0.65
PI 4.68 4.68 4.68 4.68 4.69 4.69 4.69 4.69 4.69 4.69 4.69 4.69 4.71 4.71 4.71 4.71
35
TC 12.63 12.75 12.86 12.98 13.44 13.44 13.44 13.58 13.87 13.87 14.07 14.21 14.96 14.96 14.96 14.96
S/T 0.82 0.94 1.00 1.00 0.63 0.75 0.87 0.98 0.54 0.65 0.77 0.88 0.34 0.44 0.55 0.66
PI 5.11 5.11 5.11 5.11 5.13 5.13 5.13 5.13 5.14 5.14 5.15 5.14 5.18 5.18 5.18 5.18
40
TC 11.79 11.91 12.02 12.14 12.57 12.57 12.62 12.75 12.97 12.97 13.08 13.21 14.01 14.01 14.01 14.01
S/T 0.85 0.99 1.00 1.00 0.64 0.78 0.90 1.00 0.55 0.68 0.80 0.93 0.33 0.45 0.57 0.90
PI 5.64 5.64 5.64 5.64 5.67 5.67 5.67 5.67 5.68 5.68 5.68 5.68 5.73 5.73 5.73 5.73
46
TC 10.91 11.02 11.14 11.25 11.65 11.65 11.76 11.88 12.02 12.02 12.02 12.13 13.02 13.02 13.02 13.02
S/T 0.87 1.00 1.00 1.00 0.65 0.79 0.92 1.00 0.55 0.69 0.82 0.95 0.33 0.45 0.57 0.92
PI 6.28 6.28 6.28 6.28 6.31 6.31 6.31 6.31 6.32 6.32 6.32 6.32 6.38 6.38 6.38 6.38
50
TC 10.25 10.37 10.48 10.60 10.97 10.97 11.08 11.19 11.31 11.31 11.31 11.42 12.28 12.28 12.28 12.28
S/T 0.89 1.00 1.00 1.00 0.67 0.81 0.95 1.00 0.56 0.70 0.85 0.98 0.33 0.46 0.59 0.97
PI 6.80 6.80 6.80 6.80 6.83 6.83 6.83 6.83 6.85 6.85 6.85 6.85 6.90 6.90 6.90 6.90
TC:Total Cooling Capacity (kW)
S/T:Sensible Cooling Capacity Ratio
PI:Power Input(kW)
Note: The table shows the case where the operation frequency of a compressor is fixed.

CLIVET MC2-Y 105T Specifications

General

Brand	CLIVET
Model	MC2-Y 105T
Category	Air Conditioner
Language	English
