CLIVET MC2-Y 105T Technical Manual

Specifications
 Page 51 
ID2-XY 160M+MC2-Y 160T
INDOOR
AIRFLOW
(CMH)
OUTDOOR
DB(℃)
ID WB
(℃)
16.0 18.0 19.0 22.0
ID DB
(℃)
23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0 23.0 25.0 27.0 29.0
2600
-15
TC 16.62 16.62 16.80 16.98 17.46 17.46 17.46 17.64 17.89 17.89 17.89 17.89 19.01 19.01 19.01 19.01
S/T 0.74 0.85 1.00 1.00 0.59 0.69 0.78 0.98 0.51 0.61 0.70 0.80 0.34 0.42 0.51 0.61
PI 3.76 3.76 3.76 3.76 3.75 3.75 3.75 3.75 3.75 3.75 3.75 3.75 3.74 3.74 3.74 3.74
-10
TC 16.52 16.52 16.70 16.88 17.37 17.37 17.37 17.54 17.80 17.80 17.80 17.80 18.95 18.95 18.95 18.95
S/T 0.75 0.85 1.00 1.00 0.59 0.69 0.79 0.98 0.51 0.61 0.71 0.81 0.34 0.43 0.51 0.61
PI 3.74 3.74 3.74 3.74 3.74 3.74 3.74 3.74 3.74 3.74 3.74 3.74 3.75 3.75 3.75 3.75
-5
TC 16.42 16.42 16.60 16.78 17.30 17.30 17.30 17.48 17.74 17.74 17.74 17.74 18.90 18.90 18.90 18.90
S/T 0.75 0.86 1.00 1.00 0.59 0.69 0.79 0.99 0.52 0.61 0.71 0.81 0.34 0.43 0.52 0.61
PI 3.74 3.74 3.74 3.74 3.73 3.73 3.73 3.73 3.74 3.74 3.74 3.74 3.75 3.75 3.75 3.75
0
TC 16.34 16.34 16.51 16.69 17.23 17.23 17.23 17.41 17.69 17.69 17.69 17.69 18.88 18.88 18.88 18.88
S/T 0.75 0.86 1.00 1.00 0.60 0.70 0.79 0.99 0.52 0.62 0.72 0.81 0.34 0.43 0.52 0.62
PI 3.75 3.75 3.75 3.75 3.75 3.75 3.75 3.75 3.76 3.76 3.76 3.76 3.76 3.76 3.76 3.76
5
TC 16.25 16.25 16.43 16.61 17.17 17.17 17.17 17.35 17.63 17.63 17.63 17.63 18.87 18.87 18.87 18.87
S/T 0.76 0.87 1.00 1.00 0.60 0.70 0.80 1.00 0.52 0.62 0.72 0.82 0.34 0.43 0.52 0.62
PI 3.78 3.78 3.78 3.78 3.78 3.78 3.78 3.78 3.79 3.79 3.79 3.79 3.79 3.79 3.79 3.79
10
TC 16.16 16.16 16.33 16.51 17.09 17.09 17.09 17.26 17.56 17.56 17.56 17.56 18.82 18.82 18.82 18.82
S/T 0.76 0.87 1.00 1.00 0.60 0.70 0.80 1.00 0.52 0.62 0.72 0.82 0.35 0.44 0.52 0.62
PI 3.85 3.85 3.85 3.85 3.84 3.84 3.84 3.84 3.84 3.84 3.84 3.84 3.84 3.84 3.84 3.84
15
TC 16.02 16.02 16.20 16.37 16.97 16.97 16.97 17.15 17.45 17.45 17.45 17.45 18.74 18.74 18.74 18.74
S/T 0.77 0.88 0.99 1.00 0.61 0.71 0.81 0.91 0.53 0.63 0.73 0.83 0.35 0.44 0.53 0.63
PI 3.94 3.94 3.94 3.94 3.93 3.93 3.93 3.93 3.93 3.93 3.93 3.93 3.92 3.92 3.92 3.92
20
TC 15.84 15.84 16.02 16.19 16.79 16.79 16.79 16.97 17.28 17.28 17.28 17.28 18.58 18.58 18.58 18.58
S/T 0.77 0.88 0.99 1.00 0.61 0.71 0.81 0.91 0.53 0.63 0.73 0.83 0.35 0.44 0.53 0.63
PI 4.08 4.08 4.08 4.08 4.06 4.06 4.06 4.06 4.06 4.06 4.06 4.06 4.04 4.04 4.04 4.04
25
TC 15.10 15.24 15.38 15.53 16.05 16.05 16.05 16.22 16.53 16.53 16.53 16.53 17.77 17.77 17.77 17.77
S/T 0.79 0.90 1.00 1.00 0.61 0.72 0.83 0.93 0.53 0.64 0.74 0.85 0.34 0.44 0.54 0.64
PI 4.50 4.50 4.50 4.50 4.49 4.49 4.49 4.49 4.49 4.49 4.49 4.49 4.50 4.50 4.50 4.50
30
TC 14.41 14.55 14.69 14.84 15.30 15.30 15.30 15.44 15.79 15.79 15.79 15.79 16.99 16.99 16.99 16.99
S/T 0.80 0.92 1.00 1.00 0.62 0.73 0.85 0.96 0.53 0.64 0.76 0.87 0.34 0.44 0.54 0.65
PI 4.92 4.92 4.92 4.92 4.93 4.93 4.93 4.93 4.94 4.94 4.94 4.94 4.96 4.96 4.96 4.96
35
TC 13.66 13.80 13.95 14.09 14.55 14.55 14.55 14.69 15.01 15.01 15.24 15.38 16.19 16.19 16.19 16.19
S/T 0.82 0.94 1.00 1.00 0.63 0.75 0.87 0.98 0.54 0.66 0.77 0.88 0.34 0.44 0.55 0.66
PI 5.38 5.38 5.38 5.38 5.40 5.40 5.40 5.40 5.41 5.41 5.42 5.41 5.45 5.45 5.45 5.45
40
TC 12.72 12.85 12.98 13.11 13.57 13.57 13.62 13.75 14.00 14.00 14.12 14.26 15.12 15.12 15.12 15.12
S/T 0.85 0.99 1.00 1.00 0.65 0.78 0.90 1.00 0.55 0.68 0.80 0.93 0.33 0.45 0.57 0.90
PI 5.94 5.94 5.94 5.94 5.97 5.97 5.97 5.97 5.98 5.98 5.99 5.98 6.02 6.02 6.02 6.02
46
TC 11.79 11.91 12.02 12.14 12.59 12.59 12.70 12.82 12.99 12.99 12.99 13.13 14.07 14.07 14.07 14.07
S/T 0.87 1.00 1.00 1.00 0.65 0.79 0.92 1.00 0.55 0.69 0.82 0.95 0.33 0.45 0.57 0.92
PI 6.61 6.61 6.61 6.61 6.64 6.64 6.64 6.64 6.66 6.66 6.66 6.66 6.71 6.71 6.71 6.71
50
TC 11.06 11.17 11.28 11.40 11.82 11.82 11.94 12.05 12.22 12.22 12.22 12.33 13.24 13.24 13.24 13.24
S/T 0.90 1.00 1.00 1.00 0.67 0.81 0.95 1.00 0.56 0.70 0.85 0.98 0.33 0.46 0.59 0.97
PI 7.16 7.16 7.16 7.16 7.19 7.19 7.19 7.19 7.21 7.21 7.21 7.21 7.27 7.27 7.27 7.27
TC:Total Cooling Capacity (kW)
S/T:Sensible Cooling Capacity Ratio
PI:Power Input(kW)
Note: The table shows the case where the operation frequency of a compressor is fixed.

CLIVET MC2-Y 105T Specifications

General

Brand	CLIVET
Model	MC2-Y 105T
Category	Air Conditioner
Language	English
