CLIVET MC2-Y 105T Technical Manual

Specifications
 Page 8 
Indoor model ID2-XY 105M ID2-XY 140M ID2-XY 160M
Outdoor model MC2-Y 105T MC2-Y 140T MC2-Y 160T
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Power Supply (Outdoor) V-Ph-Hz 380~415-3-50 380~415-3-50 380~415-3-50
Max. input consumption W 5600 6200 7500
Max. current A 10.0 11.2 14
Indoor fan motor
Model ZKFN-300-8-1 ZKFN-560-8-1-1 ZKFN-560-8-1-1
Qty 1 1 1
Insulation class E E E
IP rating IPX0 IPX0 IPX0
Input W 250.0 560.0 560.0
Capacitor uF / / /
Speed(Hi/Mi/Lo) r/min 1100/1000/900 1020/800/600 1060/970/905
Indoor coil
Number of rows 4.0 4.0 4.0
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.4 1.5 1.5
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 1175x294x53.48 1030x378x53.48 1030x378x53.48
Number of circuits 7 8 8
Indoor air flow (Hi/Mi/Lo) m3/h 1400/1150/750 2400/2040/1680 2600/2210/1820
ESP
Rated Pa 37 50 50
Range Pa 0-160 0-160 0-160
Indoor sound pressure level dB(A) 50/43/40 50.5/49.5/48 54/52/50.5
Indoor sound power level dB(A) 63 67 71
Indoor unit
Dimension(W*D*H) mm 1360x774x249 1200x874x300 1200x874x300
Packing (W*D*H) mm 1570x805x305 1405x915x355 1405x915x355
Net/Gross weight Kg 40.5/48.5 47.6/55.8 47.6/55.8
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODΦ25mm ODΦ25mm ODΦ25mm
Refrigerant piping Liquid side/ Gas side mm(inch) Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8")
Controller Wired control Wired control Wired control
Operation temperature °C 17-30 17-30 17-30
Room temperature
Cooling °C 17~32 17~32 17~32
Heating °C 0~30 0~30 0~30
Qty’per 20’ /40’ /40’HQ Indoor unit 49/105/120 62/130/149 62/130/149
Compressor
Model KTF310D43UMT KTQ420D1UMU KTQ420D1UMU
Type ROTARY ROTARY ROTARY
Brand GMCC GMCC GMCC
Capacity W 10010 13700 13700
Input W 2765 3700 3700
Rated current(RLA) A 5.38 7.02 7.02
Refrigerant oil/oil charge ml VG74/1000 VG74/1400 VG74/1400
Outdoor fan motor
Model ZKFN-120-8-2 ZKFN-85-8-22 ZKFN-85-8-22-2
Qty 1 2 2
Insulation class E E E
IP rating IPX4 IPX4 IPX4
Output W 150.0 126.0 126.0
Capacitor uF / / /
Speed r/min 1050 850 850
