MSAN-XMi 400T - 450T

Size Power supply

Reference

Factory code

400T

400V+N 3-phase

40 MDV-V400W/DRN1(A)

450T

400V+N 3-phase

45 MDV-V450W/DRN1(A)

Contents pag

Installation manual ………………………………………………………………………….. 5

Owner’s manual ……………………………………………………………………………… 23

This manual is for VRF SYSTEM.

To get complete and clear information, please also consider following issues:

1. please consider only 50 Hz electric supply mode

2. Installation Manual, Table 5-4 and Table 5-5: A = indoor unit standard cooling capacity in kW x 10

3. model identification

For 1 outdoor unit connected to 1 indoor unit applications please consider the following instructions. .

 Schematics refer to multiple indoor unit design:

for 1 to 1 application please consider the first indoor unit only (first line branch pipe is not needed)

 Installation Manual, Table 5-4 and Table 5-5:

for 1 to 1 application no branch pipe is needed

 Installation Manual, Table 4-8: only for VRF System

for 1 to 1 application please consider an indoor capacity range between 50% ÷ 100% the outdoor

capacity

 Installation Manual, Chapter 5.5: only for VRF System

 Owner's Manual, Chapter 1.:

for 1 to 1 application please consider 50% ÷ 100% indoor capacity range
