14 Alarms - Status
14.1 Alarms
Before resetting an alarm identify and remove its cause.
Repeated resets can cause irreversible damage.
Code Description Type
E000 Alarm phase monitor AUTO
E001 High pressure (digital) circuit *
E005 Low pressure (digital) circuit *
E010 Compressor 1 Alarm Manual
E011 Compressor 2 Alarm Time
E041 Fan thermal Manual
E045 Faulty clock error AUTO
E046 Error: Clock to set AUTO
E047 Error of LAN communication between main module and ambient keyboard (if present) AUTO
E062 Faulty exchanger temperature probe AUTO
E065 Faulty ambient keyboard temperature probe AUTO
E069 Faulty high pressure input circuit AUTO
E080 Conguration error AUTO
E081 Signalling of compressor operating hour exceeding Manual
E090 Signalling of alarm log record exceeding Manual
A = AUTOMATIC reset
M = MANUAL reset
* after some interventions is necessary the manual reset
14.2 Status
Main menu→SET→Ai, di, AO, dO→Ai L1
Menu Code Description
Ai
AiE1 Not used
Ai L1 Fan thermal (0= input closed)
Ai L2 Phase monitor (0= input closed)
Ai L3 Not used
Ai L4 High pressure transducer
Ai L5 Not used
AiR1
ambient air temperature probe
Remote control
1Ai 1 Not used
1Ai 2 Not used
1Ai 3 Not used
of
di L1 High pressure
di L2 Low pressure switch
di L3 Compressor 1 line protection
di L4 Compressor 2 line protection
di L5 Compressor 1 request
diL6 Compressor 2 request
AO
AO L1 Not used
AO L2 Not used
AO L3 Fan signal
AO L4 Not used
AO L5 Not used
To Next Page
