12 Technical information
12.1 General technical data
Size 8.2 10.2 12.2 16.2 18.2 22.2 26.2 30.2
Cooling
Cooling capacity 1 kW 25.7 31.3 36.0 43.4 51.6 59.1 72.3 80.1
Compressor power input 1 kW 8.79 9.95 12.4 14.1 16.2 20.3 22.6 26.6
Total power input 1 kW 9.20 10.4 12.9 15.6 17.7 21.8 24.2 28.4
EER 1 2.78 3.01 2.80 2.78 2.91 2.71 2.99 2.82
Compressor
Type of compressors SCROLL SCROLL SCROLL SCROLL SCROLL SCROLL SCROLL SCROLL
No. of compressors No 2 2 2 2 2 2 2 2
Std Capacity control steps No 2 2 2 2 2 2 2 2
Oil charge (C1) l 3.61 3.72 3.54 5.76 5.76 6.65 7.39 8.28
Refrigerant charge (C1) 2 kg 6.4 9.2 9.2 8.0 11.6 11.6 14.9 14.9
Refrigeration circuits No 1 1 1 1 1 1 1 1
External Section Fans
Type of fans AX AX AX AX AX AX AX AX
Number of fans No 2 2 2 1 1 1 2 2
Standard airow l/s 2553 2545 2514 4965 4902 4778 7196 6971
Installed unit power kW 0.25 0.25 0.25 1.72 1.72 1.72 0.90 0.90
CONNECTIONS
Gas connection 28 28 28 35 35 35 42 42
Liquid connection 16 16 16 22 22 22 22 22
Power supply
Standard power supply V 400/3/50+N 400/3/50+N 400/3/50+N 400/3/50+N 400/3/50+N 400/3/50+N 400/3/50+N 400/3/50+N
Noise Levels
Sound pressure level (1 m) 3 dB(A) 60 60 60 64 64 65 65 65
Dimensions
A - Length mm 1739 1739 1739 1967 1967 1967 2367 2367
B - Width mm 721 721 721 1143 1143 1143 1141 1141
C - Height mm 1287 1287 1287 1599 1599 1599 1593 1593
STANDARD UNIT WEIGHTS
Shipping weight kg 304 309 328 464 476 497 556 569
Operating weight kg 298 303 323 456 469 490 547 561
1. saturated suction temperature (SST) = 5 °C. outdoor air temperature 35°C
2. Refrigerant charge relating only to the condensing unit to be integrated according to the installation and to the evaporating
internal unit.
3. Sound levels refer to units with full load under nominal test conditions. The sound pressure is measured at 1 m from the
external surface of the unit in open eld conditions.
12.2 Sound levels
Size
Sound power level (dB)
Sound power
level
Sound pressure
level
Octave band (Hz)
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
8.2 80 75 78 73 70 66 58 52 75 60
10.2 79 74 77 73 70 66 60 51 75 60
12.2 79 74 77 72 70 67 61 52 75 60
16.2 89 82 78 80 77 69 64 59 81 64
18.2 89 82 77 79 77 71 66 60 81 64
22.2 89 82 80 81 77 72 64 59 82 65
26.2 89 82 79 80 78 73 67 59 82 65
30.2 89 82 80 81 76 73 64 57 82 65
The sound pressure level refers to a distance of 1m from the outer surface of the unit operating in an open eld.
Data referred to the following conditions:
internal exchanger water = 12/7°C
outdoor air temperature 35°C
