34 MSAT-XEE 8.2-30.2 M09G60E14-04
12.3 Operating range
1. Standard operating range
2. Operating range with modulating fans
3. Operating range with option: Min. outdoor temperature -15°C (MEN15)
4. Operating range with option: Min. outdoor temperature -30°C (MEN30)
SST = saturated suction temperature, corresponding to the
compressor suction pressure (°C)
suction gas superheating +5° K
