CLIVET Q4DN-2-XMi Series User Manual

28
Electrical connections
A
B
C
D
E
F
G
A Unit body
B Panel
C Main unit body side connector
D Panel side connector
E Protective sheath
F Connector
G Cable ties
Fig. 43
– Fasten the installation covers to the four corners by
pushing them inwards.
Fig. 44
– Refit the air intake grille, following the steps used to
remove it in reverse order.
– Fasten the door.
Cable
Bolt
Self-tapping
screw
Fig. 45
– Slide hooks into the slots
When installing the
cover, slide the four
fasteners into the
corresponding slots on
the panel.
Fig. 46
