1.4 UNIT INDENTIFICATION
Serial number label
The serial number label is positioned on the unit and allows to
indentify all the unit features.
It has not to be removed for any reason.
It reports the regulations indications such as:
 machine type, exmple:
Series  WBAN
Size  82
 serial number
12 characters  Axxxxxxxxxxx
 year of manufacture
 wiring diagram number
 electrical data
 manufacturer logo and address .
Serial number
It identifies uniquely each machine.
It identifies specific spare parts for the machine.
Assistance request
Note data from the serial number label and write them in the
chart on side, so you will find them easily when needed.
In case of intervention you have to provide data.
Serie
Size
Serial number
Year of manufacture
Wiring diagram
1.5 UNIT DESCRIPTION
1 - GENERAL
VULCAN Medium is a high temperature heat pump series
representing ideal single solution for heating, cooling and
sanitary hot water production for centralised systems, such as
in blocks of apartments, hotels and for use with collective
applications in general.
 A CLASS Energy Efficiency according to Eurovent, both
for heating and cooling.
 Ideal for all plant types including radiator systems using
hot water produced at a temperature of up to 60°C, and
ambient air at -10°C.
 A simplified system thanks to the use of a single generator
for heating and cooling that eliminates the risks and obli-
gatory maintenance costs associated with traditional com-
bustion systems.
The units in the ELFOEnergy VULCAN Medium range can
autonomously produce sanitary hot water and are set up for
use in combination with solar panel storage tanks, thus ena-
bling the direct use of solar energy.
1.6 ACCESSORIES
VERSIONS OPTIONS
D Partial energy recovery
B Water low temperature
REFRIGERANT CIRCUIT
CCCA Copper / aluminium condenser coil with acrylic lining
EOL Operating limit extension
AIR SIDE FEATURES
ECHP External fans with larger available head
"ECOBREEZE"
HYDRAULIC CIRCUIT
3DHWX Three-way valve for domestic hot water
3DHW Built-in 3-way valve for domestic hot water on the unit
IS4 Compressor insulation
- Hydronic group utility side: not required
1PUS Standard pump
1PUR Single-pump with reduced available head
1PUM Single-pump with larger available head
1PUHE High efficiency single inverter pump for primary circuit.
CACSX Domestic hot water kit control
TCDC Condensate collection pan with electric heater
ELECTRIC CIRCUIT
TASRX Compartment for multifunction keyboard
PM Phase monitor
PMX Phase monitor
SFSTR4N Disposal for inrush current reduction, for unit
400/3/50+N
PFCP Power factor correction capacitors (cosfi > 0.9)
INSTALLATION
AMRX Rubber antivibration mounts
PGFC Finned coil protection grill
PGFCX Finned coil protection grill
X = Accessory separately supplied
