5 - ELECTRICAL CONNECTIONS
EXEMPLE
4 units operate for the installation
2 units operate for the DHW in an independent and dedicated way to its storage
ACS domestic hot water
I installation
M Master: installation I
S1 Slave1: installation I
S2 Slave2: installation I + ACS2
accessory 3DHW Three-way valve for domestic hot water
accessory CACSX Domestic hot water kit control
S3 Slave3: installation I + ACS3
accessory 3DHW Three-way valve for domestic hot water
accessory CACSX Domestic hot water kit control
Indicative plumbing diagram
M
S1
S2
S3
ACS
2
ACS
3
I
