29
7 - CONTROL
7.5 USER PARAMETER
The list includes the parameters accessibile to the user.
Depending on the unit configuration of the unit some parameters may not be used.
menu CONFIGURATION > UNIT > ALLI > USER PARAMETER
ID Description Extended description
4 CompExt Enable comp. for External Temp. (0=No 1=Cool 2=Heat 3=always)
10 MantCoolEn
Enable summer maintenance 1=Yes/0=No
11 MantHeatEn
Enable winter maintenance 1=Yes/0=No
21 RemMode
Set remote inputs 0=H/C or H/DHW only or C/Solo sanitariDHW only from ID, 1=digital input no effect
51 SetCool
Summer Set Point
52 SetHeat
Winter Set Point
53 SecondSetC
Secondary summer SetPoint
54 SecondSetH
Secondary winter SetPoint
DOMESTIC HOT WATER (DHW)
The unit puts always the DHW at the set-point value p429.
During the accumulation phase the temperature falls down to
par 432.
During the maintenance phase the temperature falls down to
par 431.
It is opportune to schedule the maintenance phase by night
and during periods of lower use of domestic water.
The scheduling allows to set the daily time bands and to assign
the desired operating mode :
 Maintenance
 Maintenance + Recirculation
 Accumulation + Recirculation
 Accumulation
p 431
p 432
SET
p 429
DHW MODULE
Par Menu: Configuration - unit Value
12 Enable DHW 1
315 Address 2
316 Baud Rate 1
317 Parity 0
Par Menu: Configuration - keyboard Value
02 DHW enable 2
10 Enable network management 1
Par Parameters DHW module Value
33 Index 1
34 Baud Rate 1
35 Parity 0
I27
Ensolar
only if present solar system
1
MDS Modbus Slave 1
