CLIVET WBAN Series User Manual

30
7 - CONTROL
ID DESCRIPTION U.M.
1
Current set point
°C
2
Actual temperature difference (including
compensation)
°C
3
Timer relative to resource insertion
seconds
4
Dynamic TimeScan relative to resource
insertion
seconds
5
External T compensation
°C
6
Ambient T Compensation
°C
7
Water Reset compensation
°C
8
Charge compensation
°C
9
Duty Cycle comp
°C
10
Compensation on duration
°C
11
Utility water input temperature
°C
12
Utility water output temperature
°C
13
Auxiliary heater outlet temperature
°C
14
Fresh air temperature
°C
15
Condensing coil temperature
°C
16
Accumulation temperature
°C
17
Utility pump
0=Off 1=On
18
Utility secondary pump
0=Off 1=On
19
Source flow-rate
%
20
Condensing pressure
Bar
21
Evaporating pressure
Bar
22
Auxiliary heater control signal (0-10V)
%
23
Boiler command
0=Off 1=On
24
Boiler valve command
0=Off 1=On
25
Relative humidity
%
26
Free cooling (On-Off valve) 0=Off 1=On
0=Off 1=On
27
Variable speed compressor (0-10V)
%
28
Compressor 1 operating hours
hour
29
Comp 1 starts
Number
30
Compressor 2 operating hours
hour
31
Comp 2 starts
Number
32
Defrosting delay (SeTypeDFR = 0)
seconds
33
Defrosting count (SeTypeDFR = 0)
seconds
34
Ambient dew temperature
°C
35
Mininet
X=node discon-
nected
O=Node
connected
36
Electric power absorbed
KW
ID DESCRIPTION U.M.
37
Water input temperature 2
°C
38
Water output temperature 2
°C
39
Condensing coil temperature C2
°C
40
Ventilation (0-10V) C2
%
41
Condensing pressure C2
Bar
42
Evaporating pressure C2
Bar
43
Compressor 1 operating hours C2
hours
44
Comp 1 starts C2
Number
45
Compressor 2 operating hours C2
hours
46
Comp 2 starts C2
Number
47
Delay DFR C2 (SeTypeDFR = 0)
seconds
48
Count DFR C2 (SeTypeDFR = 0)
seconds
49
Return temperature
°C
50
Discharge temperature
°C
51
Condensing temperature
°C
52
Operative SuperHeat
°C
53
Thermostatic valve opening percentage
%
54
Actual set point in superheating
°C
55
Not used
56
Not used
57
Not used
58
Not used
59
Not used
60
Not used
61
Not used
62
Not used
63
Not used
64
Not used
65
Not used
66
Not used
67
Not used
68
Not used
69
Not used
70
Not used
71
Not used
72
Operative SuperHeat C2
°C
73
Return temperature C2
°C
7.6 STATUS
Depending on the configuration of the unit some status may not be used.
