CLIVET WBAN Series User Manual

8
Operate in compliance with safety regulations in force.
For detailed information (dimensions, weight, technical
characteristics etc.) please refer to the TECHNICAL
INFORMATION section.
Use single protection devices : gloves, glasses ecc.
During positioning consider these elements :
 technical spaces required for the machine and system
 place where the machine will be installed
 electrical connections
 water connections
 air / aeraulic ducts
Do not considerer these elements could decrease
performances and operational life of the unit.
3.1 PRELIMINARY INFORMATION
Limit vibration transmission:
 use antivibration devices on unit bearing points;
 install flexible joints on the hydraulic.
A correct circulation of the air is indispensible to guarantee the
good working order of the machine.
Avoid therefore:
 obstacles to the airflow;
 exchange difficulties;
 leaves or other foreign bodies that can obstruct the
exchange batteries;
 winds that hinder or favour the airflow;
 heat or pollution sources close to the unit (chimneys,
extractors etc);
 stratification (cold air that stagnates at the bottom);
 recirculation (expelled air that is sucked in again);
 positioning below the level of the threshold, close to very
high walls, attics or in angles that could give rise to
stratification or recirculation phenomenons.
Ignoring the previous indications could:
 energy efficiency decrease;
 blocks due to HIGH PRESSURE (in summer) or LOW
PRESSURE (in winter).
3.2 FUNCTIONAL SPACES
3.3 POSITIONING
Functional spaces are designed to:
 guarantee good unit operation
 carry out maintenance operations
 protect authorized operators and exposed people
Respect all functional spaces indicated in the TECHNICAL
INFORMATION section.
Double all functional spaces if two or more unit are aligned.
Units are designed to be installed:
 EXTERNAL
 in fixed positions.
Choose the installation place according to the following
criteria:
 Customer approval
 safe accessible position
 technical spaces requested by the unit
 spaces for the air intake/exhaust
 max. distance allowed by the electrical connections
 control points with capacity adequate to the unit weight
 condensate water draining
Prefer places where the unit doesn't disturb the neighbours.
Avoid installations next to bedrooms or windows.
Avoid snow accumulations on batteries.
Avoid installations in places subject to flooding
In case of ground installation provide a raised base to avoid
flood damages.
Protect the unit with an appropriate fencing to avoid the
access to a not authorized personnel (babies, vandals etc.)
3 - POSITIONING
3.4 CONDENSATE WATER
When a heat pump is running it produces a considerable
amount of water due to the defrosting cycles of the external
coil.
The condensation must be eliminated in a manner to avoid
wetting pedestrian areas.
With extensive very cold outdoor temperatures, condensation
could freeze and block the flow, causing a slow build-up of
ice; therefore special attention must be paid to eliminating
condensation, raising the unit off the ground and evaluating
whether antifreeze elements should be installed
