M07J40G8-00 21/07/08 page 45
1
2
4
4
7
7
7
7
14
G
5
2
5
4
4
8
9
O.D.
3
3
3
3
6
6
4
4
3
3
W1 W3
W7 W8
W2
W6
W4
W5
1100
(12)
700
(10)
1100
(12)
1690
(13)
723
(11)
2155
PO
M N
1442 2825 2880 1442
2247
2393
11414
A B C
D
2400 (+EC OBREEZE=2430 )
2825
46
46
ST SC LN
SIZE 2.540 2.600 2.540 2.600 2.480 2.540
A
mm 3570 3570 3570 3570 4120 3570
B mm 2910 2910 2910 2910 2360 2910
C mm 4934 4934 4934 4934 4934 4934
D mm 457 457 457 457 457 457
M mm 6030 5921 6015 5943 5744 5937
N mm 5384 5493 5399 5471 5670 5477
O mm 1217 1417 1008 1008 1004 1012
P mm 1030 1030 1439 1439 1443 1435
OD
mm 219.1 219.1 219.1 219.1 219.1 219.1
Length
mm 11414 11414 11414 11414 11414 11414
Depth
mm 2247 2247 2247 2247 2247 2247
Height
mm 2400 2400 2400 2400 2400 2400
W1
kg 1042 1252 1175 1297 1343 1291
W2
kg 1660 1807 1902 1907 1680 1887
W3
kg 1208 1410 1324 1458 1322 1450
W4
kg 1095 1152 1256 1250 1248 1231
W5
kg 1041 1048 953 1047 1058 1048
W6
kg 1658 1513 1543 1539 1324 1532
W7
kg 813 829 741 825 742 826
W8
kg 736 677 702 707 701 702
Operating weight
kg 9253 9687 9595 10029 9418 9967
Shipping weight
kg 8791 9236 9133 9578 9026 9505
Particular accessories, executions or versions can bring about a great variation of the mass represented here. Please contact our Technical Department..
(1) INTERNAL EXCHANGER (EVAPORATOR)
(2) EXTERNAL EXCHANGER (CONDENSER)
(3) HOLE TO HANG UNIT
(4) LIFTING BRACKETS (REMOVABLE, IF REQUIRED, AFTER
POSITIONING THE UNIT)
(5) ELECTRICAL PANEL
(6) POWER INPUT
(7) SOUND PROOF ENCLOSURE ( ONLY IN THE EXPECTED
VERSIONS)
(8) INTERNAL EXCHANGER WATER INLET
(9) INTERNAL EXCHANGER WATER OUTLET
(10) MINIMUM DIMENSION FOR A SAFE PASSAGE.
(11) MINIMUM DIMENSION FOR A SAFE PASSAGE WHEN THE
DOOR OF THE ELECTRICAL SWITCHBOARD IS OPEN.
(12) MINIMUM DIMENSION FOR A PROPER AIR FLOW TO THE
CONDENSER COIL.
IN THE CASE OF TWO UNITS SIDE BY SIDE THIS DISTANCE
MUST BE DOUBLED
(13) MINIMUM DIMENSION ON THE ELECTRICAL
SWITCHBOARD SIDE.
(14) CLEARANCE ACCESS RECOMMENDED
(G) BARYCENTRE
