TECHNICAL DATA
Acoustic configuration: Standard (ST) / Compressors insulation (SC)
Size
2.160 2.180 2.190 2.200 2.240 2.280 2.300 2.320 2.340 2.360 2.440 2.480 2.540 2.600
COOLING
Cooling capacity 1 kW 400 456 505 556 616 699 767 835 882 935 1016 1138 1272 1411
Compressor power input
kW 112 129 142 159 175 202 224 245 258 274 295 333 369 413
Total power input 2 kW 129 146 162 179 198 225 247 268 284 300 328 366 408 452
Heating capacity total recovery
kW 514 586 637 701 775 872 953 1027 1074 1155 1258 1404 1574 1732
Heating capacity partial recovery
kW 102 117 129 143 158 180 198 216 228 242 262 294 328 365
EER 3.1 3.12 3.12 3.11 3.11 3.11 3.11 3.12 3.11 3.12 3.1 3.11 3.12 3.12
ESEER 3.55 3.45 3.61 3.65 3.64 3.72 3.72 3.79 3.79 3.83 3.67 3.74 3.73 3.77
COMPRESSOR
Type of compressors 3 DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW
No. of Compressors Nr 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Std Capacity control steps
Nr
STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS
Refrigerant circuits Nr 2 2 2 2 2 2 2 2 2 2 2 2 2 2
INTERNAL EXCHANGER
Type of internal exchanger 4 S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T
No. of internal exchangers
Nr 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Water flow rate (Internal
Exchanger)
l/s 19.1 21.8 24.1 26.6 29.4 33.4 36.6 39.9 42.1 44.7 48.5 54.4 60.8 67.4
internal exchanger pressure drop
kPa 59 56 75 76 67 56 73 84 73 76 53 69 83 107
Water content l 164.4 159.3 152.7 263.3 255.7 248.3 241.2 241.2 233.3 409.6 400.9 391.9 461.8 451.4
EXTERNAL SECTION FANS
Type of fans 5 AX AX AX AX AX AX AX AX AX AX AX AX AX AX
Number of fans Nr 10 10 12 12 14 14 14 14 16 16 20 20 24 24
Standard air flow l/s 55480 55480 61250 61250 71730 71730 71730 71730 81340 81340 101540 101540 122500 122500
CONNECTIONS
Water fittings
141.3 141.3 141.3 168.3 168.3 168.3 168.3 168.3 168.3 219.1 219.1 219.1 219.1 219.1
POWER SUPPLY
Standard power supply
V 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50
(1) data referred to the following conditions :
internal exchanger water = 12/7°C
external exchanger air intake 35°C
(2) According to EUROVENT the Total Power Input does not consider the pump share, required to overcome the pressure drop for the solution circulation
inside the exchangers.
(3) DSW = twin-screw compressor
(4) S&T = tube bundle
(5) AX = axial-flow fan
