M07J40G8-00 21/07/08 page 47
Acoustic configuration: Low noise (LN)
Size
2.160 2.180 2.190 2.200 2.240 2.280 2.300 2.320 2.340 2.360 2.440 2.480 2.540
COOLING
Cooling capacity 1 kW 400 454 506 553 614 694 769 829 877 932 1020 1143 1287
Compressor power input kW 116 131 146 159 180 206 227 247 256 274 304 338 383
Total power input 2 kW 129 146 162 177 198 224 247 267 281 299 329 368 413
Heating capacity total recovery
kW 514 586 637 701 775 872 953 1027 1074 1155 1258 1404 1574
Heating capacity partial recovery
kW 103 117 130 142 159 180 199 215 227 241 265 296 334
EER 3.1 3.11 3.12 3.12 3.1 3.1 3.11 3.1 3.12 3.12 3.1 3.11 3.12
ESEER 3.65 3.64 3.65 3.71 3.74 3.81 3.81 3.85 3.81 3.83 3.85 3.85 3.83
COMPRESSOR
Type of compressors 3 DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW DSW
No. of Compressors Nr 2 2 2 2 2 2 2 2 2 2 2 2 2
Std Capacity control steps Nr
STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS STEPLESS
Refrigerant circuits Nr 2 2 2 2 2 2 2 2 2 2 2 2 2
INTERNAL EXCHANGER
Type of internal exchanger 4 S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T S&T
No. of internal exchangers Nr 1 1 1 1 1 1 1 1 1 1 1 1 1
Water flow rate (Internal Exchanger)
l/s 19.1 21.7 24.2 26.4 29.3 33.2 36.7 39.6 41.9 44.5 48.7 54.6 61.5
internal exchanger pressure drop
kPa 59 56 75 75 67 55 73 83 72 75 53 69 85
Water content l 164.4 159.3 152.7 263.3 255.7 248.3 241.2 241.2 233.3 409.6 400.9 391.9 461.8
EXTERNAL SECTION FANS
Type of fans 5 AX AX AX AX AX AX AX AX AX AX AX AX AX
Number of fans Nr 10 12 13 14 14 14 16 16 20 20 20 24 24
Standard air flow l/s 40520 45060 50500 52790 52790 52790 59180 59180 74630 74630 74630 90130 90130
CONNECTIONS
Water fittings
141.3 141.3 141.3 168.3 168.3 168.3 168.3 168.3 168.3 219.1 219.1 219.1 219.1
POWER SUPPLY
Standard power supply
V 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50
(1) data referred to the following conditions :
internal exchanger water = 12/7°C
external exchanger air intake 35°C
(2) According to EUROVENT the Total Power Input does not consider the pump share, required to overcome the pressure drop for the solution
circulation inside the exchangers.
(3) DSW = twin-screw compressor
(4) S&T = tube bundle
(5) AX = axial-flow fan
