5
1.4 UNIT INDENTIFICATION
Serial number label
The serial number label is positioned on the unit and allows to
indentify all the unit features.
It has not to be removed for any reason.
It reports the regulations indications such as:
machine type, exmple:
Series WSAT XEE
Size 352…….802
serial number
12 characters Axxxxxxxxxxx
year of manufacture
wiring diagram number
electrical data
manufacturer logo and address .
Serial number
It identifies uniquely each machine.
It identifies specific spare parts for the machine.
Assistance request
Note data from the serial number label and write them in the
chart on side, so you will find them easily when needed.
In case of intervention you have to provide data.
Typology
Size
Serial number
Year of manufacture
Wiring diagram
1.5 ACCESSORIES
1 - GENERAL
VERSIONS OPTIONS
EXC Excellence
PRM Premmium
D Partial energy recovery
R Total energy recovery
B Water low temperature
SC Acoustic configuration with compressor soundproofing
EN Extremely low noise acoustic configuration
FCD FREE-COOLING diretto (disponibile solo con opzioni:EXC)
CONFIGURATIONS
CREFP Device for consumption reduction of the external section at
variable speed (phase-cutting)
CREFB Device for consumption reduction of the external section
ECOBREEZE fans
REFRIGERANT CIRCUIT
CCCA Copper / aluminium condenser coil with acrylic lining
CCCA1 Copper / aluminium condenser coil with Energy Guard DCC
Aluminum
MHP High and low pressure gauges
OHE Limit extension kit in heating up to -10°C (W.B.)
HYDRAULIC CIRCUIT
2PM Hydropack with 2 pumps
1PUS Standard pump
1PU1SB Standard pump with emergency pump
AX00 X00-litre storage tank
AX00RPS X00-litre storage tank with primary circuit onboard
Water connections:
ABU Flush hydraulic connections
IFWX Water steel mesh strainer
SYSTEM ADMINISTRATORS
CMSC10 Serial communication module to LonWorks supervisor
CMSC8 Serial communication module to BACnet supervisor
CMSC9 Serial communication module to MODBUS supervisor
ELECTRIC CIRCUIT
RCMRX Remote control via microprocessor control
CONTA2 Energy meter
ECS ECOSHARE function for the automatic management of a
group of units
PM Phase monitor
MF2 Multi-function phase monitor
SFSTR Disposal for inrush current reduction
PFCP Power factor correction capacitors (cosfi > 0.9)
SPC2 Set point compensation with outside temperature probe
SCP4 Compensation of set point with signal 0-10 V
PSX Mains power supply (available only with options: RCMRX)
INSTALLATION
AMMX Spring antivibration mounts
PGFC Finned coil protection grill
PGCCH Anti-hail protection grilles
