Cloud Z4MK4 General Description

Clearly better sound
Technical Specications
Line inputs
Frequency Response 20 Hz - 20 kHz, ±0.5 dB
Distortion <0.08%, 20 Hz to 20 kHz
Sensitivity 218 mV (-11.0 dBu) to 3.2 V (+12.5 dBu), +/-0.5 dBu
Input Gain Control range 20 dB (unbal inputs); 22 dB (bal inputs)
Input Impedance 47 kohms
Headroom >20 dB
Noise <-90 dB A-weighted, rel. 0 dB gain
Equalisation LF: ±10 dB @ 50 Hz HF: ±10 dB @ 10kHz
Microphone inputs
Frequency Response 100 Hz (-3 dB lter) to 20 kHz, ±0.5 dB
Gain Range 10 dB to 50 dB
Input Impedance >2 kohms (balanced)
Phantom power +12 V (internal DIP switch for selection)
Headroom >20 dB
Noise -120 dB EIN, 22 Hz to 22 kHz (Z
S
=150 ohms)
Equalisation LF: ±10 dB @ 100 Hz, HF: ±10 dB @ 5 kHz
Facility inputs
Input Impedance 10 kohms (bal.); pin 3: ‘+’, pin 4: ‘-‘
Sensitivity 0 dBu (775 mV)
Noise Gate Enabled by internal jumper
Outputs
Output Level 0 dBu (775 mV) balanced
Minimum load impedance 600 ohms
Maximum output level +20 dBu (7.75 V)
General
Power Input 85 V to 253 V AC, 47 – 63 Hz
Fuse Rating 250 V – T1A H (high breaking capacity)
Fuse Type 20 mm x 5 mm 250 V
Dimensions (w x h x d) 482.6 mm x 132.5 mm (3U) x 160 mm
19” x 51/5” x 61/3”
Weight Z8MK4: 4.40 kg / 9.7lbs
Z4MK4: 3.83 kg / 8.4lbs
