Cloudray DM556S User Manual

DM556S USER MANUAL
www.cloudratmotor.com
8
200
on
on
on
on
Other Subdivision can be custom-made
400
off
on
on
on
800
on
off
on
on
1600
off
off
on
on
3200
on
on
off
on
6400
off
on
off
on
12800
on
off
off
on
25600
off
off
off
on
1000
on
on
on
off
2000
off
on
on
off
4000
on
off
on
off
5000
off
off
on
off
8000
on
on
off
off
10000
off
on
off
off
20000
on
off
off
Off
25000
off
off
off
off
DIP SW5, SW6, SW7, SW8 are used to set the number of pulses required per revolution of the motor.
Motor speed = command pulse frequency / per revolution pulse
Motor stroke = number of command pulses / pulse per revolution
4.3 Half / full flow selection
DIP SW4 is used to set the quiescent current value when the motor stops.
Off means that when the drive power-on pulse stops, the driver switches the current output to the motor to half
of the rotation (half-flow);
On indicates that the drive maintains the same current output as the rotation to the motor (full flow) when the
drive power-on pulse is stopped. In general use, SW4 should be set to off, so that the heat generated by the
motor and the driver is reduced, and the reliability is improved.
5. Drive working status LED indication
LED status
Drive status
Green indicator is on for long time
Drive not enabled
Green indicator is flickering
Drive working normally
One green indicator and one red indicator
Drive overcurrent
One green indicator and two red indicators
Drive input power overvoltage
One green indicator and three red indicators
The internal voltage of the drive is wrong
One green and four red indicators
Tracking error exceeds limits
