15
Clutches
GASOLINEENGINE,MUFFLER,FUEL
SYSTEM,ANDCLUTCHES
DRIVEBELT
SeeGeneralWarnings,Section1,Page1-2.
Thedrivebeltshouldbeinspectedperiodicallyforwearandglazing.Ifitisexcessivelyworn,frayed,orglazed,
replacethebelt.
2171
Figure15-26DriveBeltRemoval
DriveBeltRemoval
1.Disconnectbatteryandsparkplugwire(s).SeeSide-PostBattery:DisconnectingtheBattery–
Gasoline/DieselVehiclesonpage1-3.
SeeTop-PostBattery:DisconnectingtheBattery-Gasoline/DieselVehiclesonpage1-4.
2.Removetheouterclutchcover.SeeClutchOuterCoverRemovalonpage15-37.
3.Graspthebeltmidwaybetweenthedriveanddrivenclutchesandsqueezethebelttogetherastightlyaspossible
(Figure15-26,Page15-30).
4.Guidethebeltoverthedrivenclutchandrollthebeltoffthedrivenclutchbyrotatingtheclutchclockwise.
SeefollowingCAUTION.
CAUTION
•Makesureyourngersarenotunderneaththebeltwhenrollingthebeltoffthedrivenclutch.
DriveBeltInstallation
1.Positionthenewbeltonthedriveclutchandthenstartthebeltoverthetopofthedrivenclutch.
2.Rotatethedrivenclutchclockwiseandrollthebeltoverthedrivenclutchsheavesandontotheclutch.
3.Installtheouterclutchcover.SeeClutchOuterCoverInstallationonpage15-37.
4.Connectbatteryandsparkplugwire(s).SeeSide-PostBattery:ConnectingtheBattery–Gasoline/Diesel
Vehiclesonpage1-4.
SeeTop-PostBattery:ConnectingtheBattery-Gasoline/DieselVehiclesonpage1-4.
DRIVECLUTCH
SeeGeneralWarnings,Section1,Page1-2.
CAUTION
•Beverycarefulwiththeclutches.Aclutchthathasbeendroppedwillnotbeproperlybalanced.If
eitherclutchisdropped,assumethatitisdamagedandreplaceit.
Page15-302016Carryall1500/1700andXRT1550MaintenanceandServiceManual
