HYDRAULICBRAKEANDPARKBRAKE
SYSTEMSBrakePadsandCaliper
6
NOTE:Driver'ssidebrakehoseconnectionuses2hoses(6and9)andadoublelengthbanjobolt(8).(Figure
6-4,Page6-11).
Placeaclean,tray-typecontainerbelowthecaliperandbrakehoseassemblytocatchbrakeuidwhenthe
brakehoseandcaliperbodyareseparated.
4.Ifthecaliperwillbeusedagain,plugthebanjoboltholetopreventdirtanddebrisenteringthecaliper.
5.Placeaplasticbagoverthehosettingtopreventdirtanddebrisenteringthehose.
6.Removethetwosocket-headslide-pinbolts(7)securingthecaliper(2)toitsmountingbracket.
7.Pullthecaliper(2)offthemountingbracketandremovethepads.
6
1
2
3
5
4
3
7
9
6
10
3
3
4
8
2756
Figure6-3RearBrakeCaliperandPads(Passengerside)
2769
Figure6-4RearBrakeCaliperandPads(Driverside)
REARBRAKEPADANDCALIPERINSTALLATION
WARNING
•Ifatanypointinthisprocedurethehydraulicsystemisopened,thebrakesmustbebledafterthe
correctreinstallationofthebrakecomponents.Failuretobleedthebrakescouldresultindecreased
brakingperformanceduetoairbeingtrappedinthehydraulicsystem.UseonlyDOT5brakeuid.See
BleedingtheHydraulicBrakeSystemonpage6-18.
1.Placeandholdthebrakepadsinthecaliper(2)andinstallthecaliperontoitsmountingbracket.Seefollowing
NOTEandWARNING.
NOTE:Tohelppreventnoise,asilicone-basedbrakelubricantmaybeappliedtothesurfaces(onthebacksideof
thebrakepads)thatcontactthecaliper.Athinlmmayalsobeappliedtotheslide-pins.Alwaysfollow
lubricantmanufacturer’sdirections.
WARNING
•Toreducethepossibilityofdiminishedbrakeperformanceorfailure,neverusepetroleum-based
lubricantsonbrakesystemcomponents,andensurelubricantdoesnotcontactfrictionsurfacesof
brakepadsorrotors.
2.Insertthesocket-headslide-pinbolts(7)throughthecaliper(2),mountingbracketandbrakepads.Threadthe
slide-pinboltsintothemountingbracketandtightento32ft-lb(43N·m).
2016Carryall1500/1700andXRT1550MaintenanceandServiceManualPage6-11
