Paddle mixer operated in accordance with the manufacturer's instructions is trouble-free,
however, it doesn't exclude some shortcomings caused by external factors. Possible
deficiencies in the operation of the machine and how to remove them presented in Table no.
8.
No. Symptoms Reason Removal
1
Machine doesn't work
No voltage in control circuit Replace fuse
2 No power supply
Check electrical and control system
in accordance with the wiring diagram
starting from power supply of machine
3
Faulty of locking/security
devices
Check operation of locking/security
devices - table no.1 - replace faulty
device
4 Mixing shafts don't move Transmission Check the operation of the connecting
components and transmission
Table no. 8
Attention!
In case of failure, machine must be secured against access of the
outsiders and noted faults reported to the supervisor.Work with
technical malfunctioning machine is prohibited!
10. Spare parts list
Ball bearing 6208 2Z – 2pc.
Ball bearing 6011 2Z – 4pc.
Simmering 60*80*8 – 4pc.
Simmering 70*90*10 – 4pc.
Oring 21,2*3,2 – 2pc.
Oring 48,7*4 – 4pc.
Oring 90*3,55 – 2pc.
Oring 136*3,2 – 2pc.
Snap ring Z-12 – 2pc.
Snap ring Z22 – 1pc.
Snap ring Z-20 – 2pc.
Snap ring Z-35 – 4pc.
Snap ring Z-30 – 2pc.
Snap ring Z-40 – 1pc.
Engine Bonfiglioli E7,5 KW 4P B5 P132 IP55 IE2
Gearmotor Bonfiglioli 303L2- 30,8 PC P132 E
Drive sprocket – Fig. No. RX-200-01,13,,009B –1pc.
Drive sprocket (big one) – Fig. No. RX-200-01,20,006 - 2pcs.
Return sprocket- Fig. No.RX-200-01,21,003 – 1pc.
Chain 16B1 – 5 lm + 2 fasteners
Hinge CFM 425611 – 7pc.
Silicone seal 16*12 + seal 1011-20
12
