CM RX-600 - Page 11

10 1 Drive shaft of the agitator RX-600-01.20.001
11 2 Hexagon screw PN-85/M-82105 M 10 x 30
12 6 Hexagon screw PN-85/M-82105 M 8 x 20
13 6 Round washer PN-77/M-82008 8,2
14 1 Bearing housing of agitator shaft RX-600-01.02.02.00
15 6 Hexagon screw PN-85/M-82105 M 8 x 20
16 6 Round washer PN-77/M-82008 8,2
17 2 Sealing ring PN-88/M-73067 70 x 90 x 10
18 1 Bushing :1 RX-600-01.19.002
19 6 Hexagon screw PN-85/M-82105 M 6 x 20
20 6 Round washer PN-77/M-82008 6,1
21 1 Sealing ring PN-90/M-73060 G 136 x 3,55:1
22 1 Sealing lid: 1 RX-600-01.19.001
23 1 Shaft sleeve RX-600-01.15.012
24 2 Parallel key PN-91/M-85001 A A 14 x 12 x 63
25 1 Locking screw PN-87/M-82317 M 8 x 20
26 2 Sealing ring PN-90/M-73060 G 48,7 x 3,55:1
27 1 Agitator RX-600-01.15.00.02
28 1 Bushing RX-600-01.15.011
29 1 Slip ring RX-600-01.14.005
30 1 Agitator supporting sleeve RX-600-01.14.003
31 1 Sealing ring PN-90/M-73060 G 97,5 x 3,55:1
32 6 Round washer PN-77/M-82008 8,2
33 6 Hexagon screw PN-85/M-82105 M 8 x 20
34 1 Sealing ring PN-90/M-73060 G 21,2 x 2,65:1
35 1 Agitator exis RX-600-01.14.002
36 1 Securing groove RX-600-01.14.001
37 1 Round washer PN-77/M-82008 6,1
38 1 Hexagon screw PN-85/M-82105 M 6 x 20
39 1 Frontal lid of housing RX-600-01.14.004
40 1 Round washer PN-77/M-82008 6,1
41 1 Hexagon screw PN-85/M-82105 M 6 x 20
Table no. 7
Spare consumable parts like sealings of ejecting flap, o-rings, bearings, sliding bearings, and
their replacement is not covered under warranty.
11
