Matrix Y User's Manual
Specification
• 4 stereo high quality headphone outputs (1/4” TRS)
• 4 headphone output volume control knobs
(To adjust the output volume of each headphone independently)
• 1 Talk Back Mic
(The Talk Back Mic output is sent directly to the four headphone outputs, but
not to the Line Outputs)
• 1 Talk Back Mic button.
• 1 Talk Back Mic indicated LED.
• 2 Line In channel (left and right, balanced, 1/4” TRS)
• 2 Line Out channel (left and right, balanced, 1/4” TRS)
• Power switch
• Power adapter (15 VAC 1000mA)
Connections on front panel
1.
Talk Back Mic
You can talk to any one who uses headphones connected to that Matrix Y
via this Mic. Talk Back signal will be sent to the headphones, but won’t
affect the signal coming out the Line Out.
