ASSEMBLY INSTRUCTIONS
ITEM:
224401KW
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
HARDWARE IDENTIFICATION
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2. This product is for home use only and not intended for commercial establishments.
PAGE 3 OF 8
COASTERFURNITURE.COM
Phillips head screw driver is required in the assembly process; however, manufacturer does not provided this item.
NOTE:
1
2
3
4
8PCS
6PCS
8PCS
24PCS
(M8 x 20MM - RBW)
BOLT 2
(M6 x 15MM - RBW)
(M6 x 25MM - RBW)
6
7
8
30PCS
30PCS
8PCS
FLAT WASHER
FLAT HEAD SCREW
(1/4” x 19 Ø - RBW)
(M4 x 32MM - RBW)
(M6 x 35MM - RBW)
9
1PC
SMALL ALLEN WRENCH
(M4 x 100MM - BLK)
5 6PCS
(M6 x 50MM - RBW)
10
1PC
BIG ALLEN WRENCH
(M5 x 65MM - BLK)
LOCK WASHER
(1/4” x 12 Ø - RBW)
BOLT 1
BOLT 3
BOLT 4
BOLT 5
