COBAN GROUP tk303 - Introduction; Device Specifications

1. Introduction
The tracker working based on the GSM/GPRS/LBS/AGPS network and GPS
satellite positioning system, which set multiple functions of security, positioning,
monitoring surveillance, and tracking in its entirety. It can track and monitor
remote target by SMS or internet. Advantage:Long time standby,and no need
installation, just adsorb under the car bottom,itself has magnetic force.
2. Specifications
Content
12000MAH
DIM
120mm x 60mm x 30mm
Weight
250g
Band
850/900/1800/1900Mhz
Network
GSM/GPRS
GPS Chip
UBLOX7
GSM/GPRS Module
MTK6261D
GPS Sensitivity
-159dBm
GPS Start time
Cold start 45-120S
Warm start 35S
Hot start 1S
Voltages of car power
system
Input1 2-24V
Output 5V
Charger Voltage
Input 110V-220V
Output 5V
Battery
Device will send low power alarm when
voltage below 3.45V
Storage Temp
-40°C to +85°C
Operation Temp
-20°C to +65°C
Humidity
5%--95% non-condensing
