Sales Introduction – SAILOR 6222 VHF DSC Class A
Cobham SATCOM, 18 July 2013
Niels Peter Agdal
www.cobham.com
7
Up to 4 SAILOR 6204 Control Speaker Microphones can be connected to the SAILOR 6222
VHF. The SAILOR 6204 Control Speaker Microphone is waterproof to IPx6 and IPx8, which
makes it ideal for installation in exposed positions.
3.1.3 SAILOR 6208 Control Unit Connection Box
The SAILOR 6208 Control Unit Connection Box is used for easy installation of multiple
SAILOR 6204 Control Speaker Microphones. The SAILOR 6204 Control Speaker Microphone
can be connected directly to the SAILOR 6222 VHF, however it is much easier to install via
the SAILOR 6208 Control Unit Connection Box for multiple installations.
The SAILOR 6208 Control Unit Connection Box is also used for connections through the AUX
port to VDR, Alarm Panels, GPS and the External Speaker. See System Configuration
Example drawing on the next page.
The SAILOR 6208 Control Unit Connection Box is delivered including the 406209-941
Connection cable (5m) for easy connection to the SAILOR 6222 VHF. The SAILOR 6208
Control Unit Connection Box is also used in installations of multiple Control Units for the
SAILOR 6300 MF/HF.
3.1.4 SAILOR 6207 Accessory Connection Box
The SAILOR 6207 Accessory Connection Box is used for easy connection of external
equipment and accessories such as:
 Extra handset
 Hand Mircophones
 Position Input (NMEA)
