Technical specifications
36
Transmitter
Receiver
Water ingress protection IP67
Frequency stability Better than ±0.7 kHz
Weight with emergency battery 370g
Item Specification
RF output power 2 W /1 W
RF output power, Canada 1.7 W ±0.7 dB / 0.8 W ±1 dB
Max deviation
25 kHz
12.5 kHz
±5 kHz
±2.5 kHz
Spurious emission < 0.25 uW
Adjacent channel power
25 kHz
12.5 kHz
> 70 dB
> 60 dB
Item Specification
Sensitivity (20 dB SINAD) -117 dBm typical
Item Specification
0740
