Helm & Command Link Gauges
Switch Panel & Helm
At the helm of your Cobia, you have a
main switch panel, which is located above
the steering wheel. This panel controls
your lights, horn, accessories, livewell,
and your bilge. When a switch is in the
“on” position, its tip is illuminated. This alerts you that the associated accessory should
be functioning and also reminds you to turn it off during boat shutdown. When the
“NAV” light switch is in the “on” position, the labels for the switches will be illuminated.
To the right of the steering wheel you have your two trim tab switches. The boat also
comes standard with a compass mounted on top of the console.
When the indicators above the bilge switches are illuminated in red that means the bilge
pump is running from its float switch being activated. It is not uncommon for the float
switches to be activated for a few seconds for a couple periods over the course of a full
day on the water. However, if the bilge indicators stay on for a prolonged period or come
on numerous times, this is likely evidence of a leak and the bilge should be checked
immediately for water intrusion. Any leaking should be addressed right away. For more
information on the bilges, bilge pumps and bilge switches, refer to page 11.
Command Link Gauges
Yamaha’s new 6YC Command Link gauge
comes standard on your new Cobia. This
gauge allows access to more information and
is user-selectable so you can choose the
functions displayed. Speed data can be
displayed from a pitot tube, Triducer, or
NMEA protocol GPS unit. To learn the gauge’s
full functionality, refer to your Yamaha engine
owner’s manual located in the Cobia Duffel
Bag.
Yamaha Command Link Gauge
