Drive settings for both modes can be adjusted individually and remain
even if smartphone and e-bike are not connected.
A double press of the power button allows you to switch between the two
driving modes. The second mode switches colors for the LEDs from blue
to sea green.
Only start pedaling if seated securely on your Coboc e-bike. As
soon as pressure is applied to the pedals, the motor support is
set free. If you want to sit on your e-bike by putting on foot on
the pedal while swinging over the saddle with the other leg, be aware that
the e-bike might abruptly start moving. Risk of falling!
Stop pedaling in time. Motor support is stopped as soon as the crank
stops turning. Be aware of this especially before road crossings and curves.
If you have any problems with your drive (ie. because you did not stop
pedaling in time) you may always stop the motor by using the rear wheel
brake.
Handling Battery & Charger
Reach
Your Coboc e-bike is equipped with a modern lithium-ion battery. This
type of battery offers the best state-of-the-art energy density, which means
maximum reach at minimum weight. Furthermore, lithium-ion batteries
have no memory effect. This battery has a nominal voltage of 36 volts and
a nominal capacity of 380 Wh.
The battery on your Coboc e-bike is installed into the e-bikes
frame. This way of installation allows for a very low vehicle weight
while providing ideal protection against moisture. The battery
remains in the frame even for charging. Only trained personnel is allowed
to remove the battery.
Do not remove the battery by yourself! Under no circumstances
should the cover at the bottom of the down tube be opened.
Only trained personnel should carry out maintenance or repairs
on the installed drive system. Carrying out maintenance or repairs may
result in danger to life due to live parts such as cables and contacts.
Furthermore, the drive system is being protected against moisture by a
special sealing technology, which is why warranty obligations become inva-
lid if the down tube is being opened without the approval by Coboc.
Reach: The range of your Coboc e-bike is heavily dependent on various
inuencing factors and can therefore uctuate. These include the following
factors, among others: the type of surface, incline/slope of the route, wind
conditions, tire characteristics, air pressure, driver weight, cadence, driving
speed and temperature. The settings of the drive parameters also have an
impact on the range of your Coboc e-bike. Information about the Coboc
app and the setting of the individual drive parameters can be found here:
www.coboc.biz/en/the-coboc-app/.
With a fully charged battery and on level terrain, preset mode 1 (blue
LEDSs) can be used to achieve approx. 75-110 km. When driving on as-
phalt roads, a low tire pressure can increase the rolling resistance and thus
reduce the range. Headwinds or hilly terrain will also have a negative im-
pact on the range. Increasing the drive parameters via the Coboc app will
express itself in stronger support but in return in a shorter range. A higher
total weight will also reduce the range of your Coboc e-bike. If you drive
