Tightening Torques
Category Screw Tool Torque
front wheel thru axle hex 5 mm 12-15 Nm
rear wheel axle screw spanner 18 mm 35-40 Nm
handlebar / stem stem (steerer clamping) hex 5 mm 5 Nm
handlebar / stem stem (handlebar clamping) hex 4mm 5 Nm
handlebar / stem handlebars hex 2.5 / 3 mm 2 Nm
handlebar / stem cover steerer tube hex 5mm 0.5-1Nm
handlebar / stem brake lever (clamping) hex 5mm 6-8Nm
braking system caliper hex 5mm 5-7Nm
braking system brake disc front / back torx 25 6 Nm
saddle saddle clamping hex 5mm 8-10 Nm
saddle seatpost clamping hex 4mm 4-6 Nm
mechanical drive pulley crank hex 5 mm 13-15 Nm
mechanical drive slider plates hex 5mm 20-25 Nm
attachment parts crank hex 8mm 40-45 Nm
attachment parts pedals hex 6 mm 30-40 Nm
