12
S/RF Power Meter
Shows relative transmitter RF output power and
input signal strength when receiving.The LED
(Light Emitting Diode) segments glow green to
amber to red...this indicates receive or transmit
activity.
RX/TX Indicator LED
RX indicator will light when in the receive mode.
TX indicator lights when in transmit mode.
When weather channel is selected,WX indicator is
illuminated, and the channel is displayed.
S/RF
PowerMeter
Operation
To Next Page
