Part 7 Replacement Parts List
Replacement Parts List
When ordering spare parts, please quote the part number and the description as listed below. If the part
required is not listed below, request the part by description and quote model number and serial number
which is shown on the rating plate.
Open Burners
230014 Pot Stand.
230088 Pot Stand Support.
230631 Front Burner Assy.
230632 Rear Burner Assy.
230288 Burner Cap.
230637 Gasket Burner Assy.
037210 Injector (Nat. Gas) Ø 2.10mm.
037130 Injector (LP Gas) Ø 1.30mm.
037120 Injector (Butane) Ø 1.20mm.
037380 Injector (Town Gas) Ø 3.80mm.
018680 Gas Control Pintossi 20N (Standard Burners Only).
231560 Gas Control Pintossi 20S (Flame Failure '-F' Models Only).
019428 Thermocouple - (320mm).
230671 Thermocouple - (500mm).
230606 Knob - Open Burner.
Griddle
014105 Griddle Burner.
230213 Griddle Reflector Assy.
227403 Gas Control Valve.
230608 Knob - Griddle.
032200 Injector (Nat. Gas) Ø 2.00mm.
032125 Injector (LP Gas) Ø 1.25mm.
032120 Injector (Butane) Ø 1.20mm.
032340 Injector (Town Gas) Ø 3.40mm.
019215 Pilot Burner (Fully Assembled).
026488 Pilot Injector (Nat. Gas) 0.35.
019217 Pilot Injector (LP Gas / Butane) 0.23.
018067 Pilot Injector (Town Gas) 0.60.
019428 Thermocouple - (320mm).
230586 Piezo Ignitor.
228047 Piezo H.T. Lead.
230289 Grease Tray (1 per 300mm Griddle Section).
230059 Griddle Plate 300mm.
230084 Griddle Plate 600mm.
230091 Griddle Plate 900mm.
230091 Griddle Plate 900mm (CR9 Only).
IMPORTANT:
Only genuine qualified replacement parts should be used for the servicing and
repair of this appliance. The instructions supplied with the parts should be followed
when replacing components.
For further information and servicing instructions, contact your nearest qualified
service branch (contact details are as shown on the reverse of the front cover of this
manual).
