Cobra G100 - Optional Components and Connections; Emergency Panel Connection; Internal Buzzer Connection

MARRONE / BROWN
3A
AUX1
ROSSO/ RED
+ 15
GXXX
VERDE-ROSSO / GREEN -RED
MARRONE-ROSSO/ BROWN-RED
(RV0003NMSAA)
OPTIONAL
PANNELLO DI EMERGENZA
PER CHIAVE JACK /
EMERGENCY PANEL FOR JACK
KEY: CODE AM0939EUSAA
OPTIONAL
COLLEGAMENTO PER IL
BUZZER INTERNO /
INTERNAL BUZZER CONNECTION:
CODE RV0003NMSAA
