Cobra RM4140V User Manual

11
Fig.5A
Fig. 5B Fig. 5C Fig. 5D
5.5 REMOVE THE BATTERY (Fig.6A/Fig.6B)
1. Lift and hold up the battery door
2. Press and hold the battery latch button (1) at the bottom of the battery pack.
3. Remove battery pack from the product.
Fig.6A Fig.6B
5.6 ADJUSTING THE HANDLE HEIGHT
1. Back out the locking knobs which fixed the lower handle. (Fig.7A/Fig.7B)
2. Refer to Fit.7C, move the lower handle up and down, adjust it to the proper height. There is 3 adjusting
heights to choose on this lawn mower; at 1 height, lower handle to the ground is highest, 3 height is the lowest.
3. Adjust to the required height, then fix the lower handle by the locking knobs.
1

Cobra RM4140V Specifications

General

Brand	Cobra
Model	RM4140V
Category	Lawn Mower
Language	English
