WARNING: The left side and right side of lower handle must adjust to the same height.
Fig.7A Fig.7B
Fig.7C
6. ADJUSTMENT OF THE CUTTING HEIGHT
Apply outward pressure to disengage lever from the rack. Move the lever forward or back to adjust the height.
The height (the blade to the ground) can be adjusted from 17mm (position 1) to 75mm (position 6), 6 height
positions.
Fig.8A Position 6 Fig.8B Position 1
WARNING: Make this adjustment only when the blade is stopped.
WARNING: Disconnect the electric cord from the power supply.
