Coby TF-DVD7750 - Location.of.controls; Main Unit

9
LOCATION OF CONTROLS
2
3
1
Up
ENTER
4
6
5
9
8
7
16 18 17
11 12
13 14 15
10
19
21
22
20
24
25
23
Main Unit
Left View
Battery Compartment Release Latch
Hold Switch
Power Switch
Headphone Out (1)
Front View
Left Speaker
LCD Display
Remote Sensor
Power Indicator
Right Speaker
Play / Pause
Stop
LCD Display On/Off
Enter Key
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Navigation Keypad
(Left, Right, Up, Down)
Disc Compartment Latch
Mode
Previous/Reverse
Next/Forward
Right View
Battery Indicator
DC 9V Power In
Composite Video Out
Stereo Audio Out
Coaxial Digital Audio Out
Headphone Out (2)
Volume Control Dial
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
