LOCATION OF CONTROLS
Rear Panel View
15-pin D-sub VGA In (PC)
HDMI In (HDMI)
3.5mm Audio In (PC Audio)
Component 1
RCA Audio In (L/R): Use with Component Video 1
Component Video 1 In (Y, Cb/Pb, Cr/Pr)
Component 2
RCA Audio In (L/R): Use with Component Video 2
Component Video 2 In (Y, Cb/Pb, Cr/Pr)
AV Out
SPDIF Digital Audio Out
Composite Video Out
RCA Audio Out (L/R):
AV In (S-Video, Video, DTV, TV)
S-Video In
Composite Video In
RCA Audio In (L/R): Use with S-Video or Composite Video In
75Ω Coaxial Antenna In (DTV, TV)
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
1
6
4 5 9
8
10
7
12 14
3
2
11
13
