Checking the oil level/changing the oil
Important: Always get someone to help you change/check theoil. Itwill be easier and safer if two
people are involved and can assist eachother.
The first oil change should take place after 50 hours of operation and thereafter after every 250 hours of operation.
Checking the oil level
1. Remove thewheeled left support legs and stand
thelog splitter on its end as shown in thepicture.
3. Unscrew thedipstick and wipe itclean.
Insert thedipstick into theoil cylinder but do not screw iton. Remove thedipstick and check theoil
level. Theoil level should be between thetwo grooves on thedipstick.
4. Screw thedipstick back inagain. Donot overtighten thedipstick, doing so could damage theseal.
2. Make sure that thearea around theoil dip-
stick is clean and free from dust and debris.
