Cocraft LS5T - Changing the Oil; Troubleshooting Guide; Responsible Disposal; Specifications

13
ENGLISH
Changing the oil
1. Follow steps 1 and 2 in theChecking theoil level sectionabove.
2. Suction out theoil using anoil suctionpump. Taketheused oil to your local household recycling site for
safe disposal.
3. Replace theold oil with new oil (3.2 litres of hydraulic oil).
4. Check theoil level and screw thedipstick back onagain. Donot overtighten thedipstick, doing so
could damage theseal.
Troubleshooting guide
The log doesn’tsplit. • Log improperly positioned. Turnthelog
around or rotateit.
• The log is too big or toohard.
• The wedge is blunt or damaged. Sharpen
thewedge (refer to theCare, maintenance and
storage section).
• Oil pressure low, check theoil level (refer to
theCare, maintenance and storage section).
The hydraulic ram moves jerkily,
makes strange noises
and vibrates heavily.
Oil pressure low, check theoil level (refer to
theCare, maintenance and storage section).
The motor does notstart. • Is theplug securely connected to thewall
socket?
• Is thewall socket energised?
Responsible disposal
This symbol indicates that theproduct should not be disposed of with general householdwaste.
Thisapplies throughout theentireEU. Inorder to prevent any harm to theenvironment or health
hazards caused by incorrect waste disposal, theproduct must be handed in for recycling so that
thematerial can be disposed of in aresponsible manner. Whenrecycling your product, take it to
your local collection facility or contact theplace of purchase. Theywill ensure that theproduct is
disposed of in anenvironmentally sound manner.
Specications
Rated voltage 230 V AC, 50 Hz
Power 1500 W S3 80%
IP rating IP54
Log capacity Ø 50–250 mm, length 150–520 mm
Rec. operating temp +5 °C to + 40 °C
Splitting force 5 t
Hydraulic oil 3.2 L
Size 1560 x 590 x 1330 mm
Weight 71 kg
