Cocraft LS5T - Assembly

7
ENGLISH
5 4 4 6
Q
R
I 9 139912H 4 6J
8
5
S 11
8
5 4 4 6
5 4 4 6
A End guard
B Control lever guard
C Control lever
D Power switch
E Front guard
F Log collector table
G Electric motor
Assembly
Important
Always get someone to help you assemble thelog splitter. Thelog splitter is heavy and it will be easier and
safer if two people carry out theassembly.
When splitting logs however, you must always operate thecontrols of themachine by yourself. Twopeople
must never operate themachine at thesametime.
1. Wheeled left support legs
2. Right support legs 3. Handle
4. Attaching thesupport legs to thelog splitter
Turn thelog splitter upside down and bolt thelegs ontoit.
