Cocraft LS5T - Instructions for Use; Handle

9
ENGLISH
1 2 2 3
10
7
7
4
4
4
5
4
4
5
5
Instructions for use
Handle
1. The handle can be raised to make it easier to move thelog splitter.
10. Attaching thecollector table
2. Undo thetwo locking knobs and
remove thecoachbolts.
3. Lift thehandle up until theholes in theend line up with
thelower holes in thelegs, refit thecoach bolts and tighten
thelockingknobs.
9. Attaching thecontrol lever guard
