Code 3 H2 Covert User Manual

Page 2 of 12
Standard Features
The H
2
Covert system offers the following features:
- Primary Tones: Wail, Yelp, Hi-Lo, Hyper-Yelp, Hyper-Lo, Whoop, Manual Wail, Air Horn
- Vehicle Light Control Buttons – 7 levels: 3 Progressive, Auxiliary
- PA with Built-In Noise Cancelling Microphone
- Integrated Volume Control
- Radio rebroadcast
- Stand-By
- Siren Scroll
- Park Kill
- Horn Ring Transfer
- EU Lock
- Backlit Buttons with On/Off Color Change
- Three (3) Backlight Dimming Levels and Backlight Off Option
- Two (2) Push Button Programmable Siren Controls
- Two (2) Programmable Air Horn Pitch Controls
- Externally accessible fuses
- 25’ Extension Cable
Unpacking & Pre-Installation
After unpacking the siren, carefully inspect the unit and associated parts for any damage that may have been caused in transit. Report any
damage to the carrier immediately.
Parts included in the box:
- Siren(amplier)
- Hand-Held Controller with Base
- 25’ Extension Cable
- Parts Bag
Installation & Mounting
The hand-held controller may be mounted in various locations in the vehicle: below the dash, on the tunnel, etc. using the hardware supplied.
Easeofoperationandconveniencetotheoperatorshouldbetheprimeconsiderationwhenmountingthesirenandcontrols.Theamplier
may be mounted at an appropriate location within the vehicle, and the 25’ extension cord can be used to couple the hand-held controller to the
amplier.
WARNING!
All devices should be mounted in accordance with the manufacturer’s instructions and securely fastened to vehicle elements of suf-
cient strength to withstand the forces applied to the device. Ease of operation and convenience to the operator should be the prime
consideration when mounting the siren and controls. Adjust the mounting angle to allow maximum operator visibility. Do not mount
the Hand-Held Controller in a location that will obstruct the drivers view. Mount the Hand-Held Controller mounting base in a convenient loca-
tion to allow the operator easy access. Devices should be mounted only in locations that conform to their SAE identication code as described
in SAE Standard J1849. For example, electronics designed for interior mounting should not be placed underhood, etc. Controls should be
placed within convenient reach* of the driver or if intended for two person operation the driver and/or passenger. In some vehicles, multiple
control switches and/or using methods such as “horn ring transfer” which utilizes the vehicle horn switch to toggle between siren tones may be
necessary for convenient operation from two positions.
*Convenient reach is dened as the ability of the operator of the siren system to manipulate the controls from their normal driving/riding posi-
tion without excessive movement away from the seat back or loss of eye contact with the roadway.
The H
2
Covertamplierisnotwaterproof.Itmustbemountedinalocationthatisshelteredfromrain,snow,standingwater,etc.Itmustbealso
installed in an adequately ventilated area. Do not install near heater ducts or under the vehicle’s hood. Using the mounting holes on the ampli-
erasatemplate,scribefourdrillpositionmarksatthemountinglocations.Besurethatbothsidesofthemountingsurfaceareclearofparts
that may be damaged. The siren accessory kit with mounting hardware supplied provides the user with a choice of mounting hardware. Secure
the H
2
Covertampliertothemountingsurface,usingthemountinghardware,includinglockwashers.
Connection between the hand-held controller and the H
2
CovertamplierboxisanRJ45connector.
