Code Blue CB1 Series - Programming

Mode Number
Primary-Steadyburn Mode
Secondary-Flash Mode
1
High
Single - 60 FPM
2
OFF
Single - 60 FPM
3
Low
Single - 60 FPM
4
High
Single - 150 FPM
5
OFF
Single - 150 FPM
6
Low
Single - 150 FPM
7
High
Single - 375 FPM
8
OFF
Single - 375 FPM
9
Low
Single - 375 FPM
10
High
Neobe - 75
11
OFF
Neobe - 75
12
Low
Neobe - 75
13
High
Neobe - 150
14
OFF
Neobe - 150
15
Low
Neobe - 150
16
High
Double - 125
17
OFF
Double - 125
18
Low
Double - 125
19
High
Double - 250
20
OFF
Double - 250
21
Low
Double - 250
INPUT VOLTAGE RANGE: 12-24V AC or DC
TEMPERATURE RATING: -40°C to +65°C (-40°F to 149°F)

TYPICAL POWER CONSUMPTION AT 25°C
Voltage Flash Mode
Steady Mode - High
12V DC
0.24 A Max
0.24 A
24V DC
0.12 A Max
0.12 A
12V AC
1.1 A rms Max
0.53 A rms
24V AC
0.22 A rms Max
0.22 A rms
NOTE: Average current draw in Flash Mode will vary by selected Flash mode. The above maximum amperage draw is
stated at Single 60 FPM.
5 Programming
PROGRAMMING PRIMARY & SECONDARY MODES
CB 1 Series
Administrator Guide
GU-157-FF
1. Remove power from unit.
2. Short the Yellow wires together.
3. Restore power to the unit and wait until the unit begins to flash. Once the unit begins to flash, remove the short. The unit will
alternately demonstrate the Secondary-Flash Mode and Primary-Steadyburn Mode that will be displayed during operation. For
approximately 4 seconds the Secondary-Flash Mode will be demonstrated, followed by the Primary-Steadyburn Mode.
4. To select the next mode of operation, momentarily short the yellow wires. The unit will cycle to the next mode in the list above.
5. There are seven Flash Modes and three Steadyburn Modes combinations to choose from.
6. When you reach the desired mode of operation, remove power from the unit. You MUST leave power disconnected for 20 seconds
BEFORE reapplying. When power is reapplied, the unit will operate as programmed above.
NOTE: If you do not leave power disconnected for 20 seconds before reapplying power, the light will default to Program Mode.
page 16 of 31
