Programming Commands (continued)
Programming Hang Up Methods
Command Explanation Format Default
40 Polarity Reversal/WINK 40<Polarity Reversal/WINK time># 2#
41 Revert back to dial tone 41<length of dial tone># 00#
42 Silent time out 42<silence time># 0#
43 Repeating (reorder) tone 43<number of reorder tones># 00#
44 Call time out 44<call time># (30-second notier) 10#
45 WINK Voltage Minimum 45<Voltage># 0#
46 Minimum Ring Voltage
Detection
46<0, 1 or 2># 0#
47 Maximum Ring
Frequency
47<0, 1 or 2># 0#
NOTES: FORMAT VALUE PARAMETERS
Command 40 = WINK time: 0 - 9
0 = disabled
1 - 9 = 100 - 900 milliseconds
Command 41 = Length of dial tone: 00 - 99
00 = disabled
01 - 99 = 1 - 99 seconds
Continuous sound for this period will initiate hang up
Command 42 = Silent time out: 0 - 9
0 = disabled
1 to 9 (10 to 90 in 10-second increments)
Command 43 = Number of repeating tones: 00 - 99
00 = disabled
01 - 99 = 1 - 99 cycles
Command 44 = Call time out timer: 00 - 99
00 = disabled
01 - 99 = minutes
A DTMF “BBBBB” notier plays to both parties 30 seconds prior to expiration
Command 45 = Minimum “voltage change” to interpret as a “WINK”
0 = 5V thru 9 = 14V
Command 46 = Minimum Ring Voltage Detection Threshold measured in Vrms
0 = 13, 1 = 19
2 = 40
Command 47 = Maximum Ring Frequency measured in Hz
0 = 75, 1 = 50, 2 = 35
