CHECK OPERATION OF THE CODED FRONT PLATE
On models CL505, CL515 and CL525 a Code Free Access
mode is available. This is signified by a button with a black
dot (bottom left hand button) which replaces the normal
X button. In normal operation the code needs to be entered
every time to turn the lever. To put the lock into Code Free
Access mode first enter the code on the code card followed
by the dot passage set button. The lock will now be in Code
Free Access mode. To put the lock back to Code Access only
press the dot passage set button once followed by the ‘C’
button. Turn the front plate over and note that the coloured
tumblers inside correspond to the code. The code may be
entered in any sequence, i.e. 1370 may be entered as 3710
or any other sequence of those numbers. There are a total
of 2,047 codes available on the CL500, CL510 and CL520
locks, any of which may be entered in any order. There are
1,023 codes available on the CL505, CL515 and CL525.
If you intend to change the code you should do it, if
convenient, before installing the lock – see the Code
Change Instructions in the separate sheet.
CHECK THAT THE CONTENTS OF YOUR BOX
ARE CORRECT ACCORDING TO THE MODEL
BOX CONTENTS
1 Front plate and handle ✓ ✓ ✓
2 Back plate and handle ✓ ✓ ✓
3 Neoprene seals x 2 ✓ ✓ ✓
4 Coloured, silver and butterfly spindles ✓ ✓ ✓
5 Fixing bolts x 5 ✓ ✓ ✓
6 Spare code tumblers x 2 ✓ ✓ ✓
7 Tweezers for code changing ✓ ✓ ✓
8 Allen key ✓ ✓ ✓
9 Euro profile cylinder escutcheons 1 pair - 1 pair
9a Keyhole escutcheons 1 pair - -
10 Mortice latch, strike & 4 screws - ✓ -
11 2 bolt mortice lock and strike - - ✓
12 Double euro profile cylinder & 3 keys - - ✓
13 Adaptor kit for mortice locks
with horizontal fixings ✓ - -
14 Latch support post - ✓ -
15 Spring drive assembly & screws ✓ ✓ ✓
16 2 keys - key override models only ✓ ✓ ✓
• Installation template - ✓ ✓
• Code change instructions ✓ ✓ ✓
• Code card ✓ ✓ ✓
Contents CL500 CL510 CL520
CL505 CL515 CL525
