CODELOCKS CL5000 - AUDIT TRAIL AND SYSTEM CONFIGURATION; ACTIVATE AUDIT TRAIL FUNCTION

8
ACTIVATE AUDIT TRAIL FUNCTION
1. Setdate,time,daylightsavingandDoorIDonlock.See 
 Program16,page9.
2. InsertCodelocksUSBStickintoPC.Followingprompts,install
 datamanagementsoftware(DMS).   

•
ActivateCodelocksUSBStickbyclickingonthe“Tools”menu
 andselect“ActivateUSB”

•
ClosedownDMSandremoveUSBStickfromPC
3. InsertUSBStickintolockUSBport.
4. Enter: # MasterCode
•
19
•
1
••
followed by
•
(flash for 35 seconds). AudibleBEEPwillsignifyprocess 
 complete.
5. RemoveUSBfromlockandinsertintoPCUSBport.
6. OpenDMSandclickon“OpenUSB”button.
7. Clickondatafileinlefthandcolumn.Thedatafilewillmatchthe
 DoorIDsetin1above.
8. Followingonscreenprompt,enterMasterCodeforlock. 
 Note:No # prefixrequired.
9. “MainSettings”and“UserIDSetting”cannowbemodifiedor 
 addedbyclickingoneithersettingstabtomakechanges 
 required.
10.Oncechangeshavebeenmade,click“SavetoUSB”buttonat 
 bottomofscreen.
11.RemoveUSBStickfromPCandinsertintolockUSBport.
12.Enter: # MasterCode
•
19
•
2
••
followed by
•
(flash
for 10 seconds)
•
(flash for 35 seconds). AudibleBEEPwill 
 signifyprocesscompleteandchangesuploadedtolock.
Note:MasterCodeusedinPoint12mustbeMasterCodeinstalled
onlock.
If Master Code has been changed, it will only be active after
successful data upload to lock.
PROGRAMMING
ONLINE HELP
Additionalinformationisavailableat:
www.codelocks.com/help/audit
3
Note 1: Auditinformationandprogramsettingscanbe
uploaded/downloadedtoandfromthePCandlockviathe
activatedUSBStickusingProgram19.
Note 2: WhenProgram16isactive,theAuditTrail
Functionisautomaticallyenabledforallpreviouslyinstalled
andnewUserCodes.
Note 3: Programs17,18and19willnotworkuntil
Program16isactive.
Note 4: Ifdaylightsaving(DST)isenabled,systemwill
auto-adjusttime.Ifdaylightsavingis not required,enter
0000inthestartandendDSTsectioninProgram16.
Ifthestartdateandenddateofdaylightsavingshould
changeinsubsequentyears,adjustyoursettingsinthe
DataManagementSoftware(DMS).
ForassistancewithDST,goto:
www.codelocks.com/help/dst
Note 5: Shouldbatterypowerfailformorethan24hours,
Program16willneedtobere-enteredtoresettheclock
time.Allprogramfeatureswillberetained.
