COEF MASTERSHOW 512 - Dimensions and Panels

Pag.2
DIMENSIONS and PANELS
DMX OUT1
DMX OUT3
DMX OUT2
DMX OUT4
MIDI
OUTIN THRU
MIC RS 232
LR
AUDIO IN
MADE IN ITALY
COEF HIGH SPEED SERIAL INTERFACE
CHSSI POWER SUPPLY
25 VDC 20% 0.5A
+
-
PIN 1=GND
PIN 2=SIGNAL -
PIN3=SIGNAL+
Ponte Buggianese (Pistoia)
max 130 mm.
Figure 2
POWER
16151413121110987654321
CHANNELS
PROJECTORS
LIBRARY
PROGRAMS
TIMES
PROGRAMS SECTION
PROJECTORS SECTION
LIBRARY SECTION
CHANNELS SECTION
TIMES
SECTION
DISPLAY SECTION
483.00
465.00
133.50
146.00
488.15
133.50
Figure 3
