Coelbo SWITCHMATIC 1 User Manual

2
GENERAL
Read carefully the instructions before installing this unit. Verify the tech-
nical characteristics of the motor in order to assure the compatibility with
the device.
DESCRIPTION (diagram A)
SWITCHMATIC 1 is an electronic pressure switch with integrated digital
manometer. It manages the start and stop of a single-phase pump up to
2.2kW (3 HP) (SW1-2). Cut-in and cut-out pressures are easily adjustable
through the users control panel.
Wiring is analogous to the traditional electromechanical switch.
It can operate as a dierential pressure switch and as reverse pressure
switch.
Unit SWITCHMATIC 2 in addition to all the features of the basic SWITCH-
MATIC includes instantaneous reading of current drawn. This patented
system controls and manages the overcurrent, dry-run operation and
fast-cycling.
Unit SWITCHMATIC 2 in addition to all the features of individual assembly
includes the option to be synchronized to another unit SWITCHMATIC 2
managing and protecting 2 pumps operating in cascade with alternated
starting sequence. The SWITCHMATIC 3 unit is ideal for a control panel as
it has a dry contact output.
CLASSIFICATION AND TYPE
According to IEC 60730-1 and EN 60730-1 this unit is a control sensor
device, electronic, independent assembly, programming type A with action
type 1B (microdisconnection). Operating value: I <20% I learned. Pollution
degree 2 (clean environment). Rated impulse voltage: cat II / 2500V. Tem-
peratures for ball test: enclousure (75) and PCB (125).
OPERATING CHARACTERISTICS (diagram C)
• Adjustable cut-in and cut-out pressures.
• Integrated digital pressure gauge with bar and psi indication.
• Inner pressure transmitter.
• Dry-run protection:
• Through minimum adjusted height for basic SWITCHMATIC 1/3.
• Through the instantaneous current consumption in case of SW2.
• Overcurrent protection.
• Overvoltage protection.
• ART Function (Automatic Reset Test). When the device has stopped
the pump by the intervention of the dry-running protection system,
the ART tries, with scheduled basis, to re-start the pump in order to
restore the water supply. See “ART. Automatic reset function“. Must be
activated in the step 6 of the ADVANCED MENU (Ar1).
• Fast cycling: when the hydropneumatic tank has lost too much air and,
consequently, frequent start-stop cycles are produced this alarm is
activated and is delayed the start of the pump. Activated (rc2).
• Manual start push-button (ENTER).
• 3 operation modes: dierential, reverse and synchronized.
• Control panel with 3-digit display, LED indicator lights and push-
buttons.
• Available settings:
• Stand-by mode.
• Minimum period between fast cycles.
• Start and stop delay.
• Volt-free contact for monitoring the alarms displayed in the screen (only
version A).
TECHNICAL CHARACTERISTICS
• Rated motor power: 0,37-2,2 kW (SW1-SW2)
• Power supply: ~1 x 110-230 V (SW1-SW2)
~1 x 48-230 Vac/Vdc (SW3)
• Electric outlet: Dry contact (SW3)
• Nominal pressure 1MPa/10bar (plus: 1,3MPa / 13bar)
Frequency: 50/60Hz
• Max. current: 16 A, cos  ≥ 0.6
• Protection degree: IP55
• Max water Temperature: 50ºC
• Max environment Temperature: 60ºC
• Cut-in range (start pressure) 0,5÷7 bar (version plus=11 bar)
• Cut-ot range (stop pressure) 1÷8 bar (version plus=12 bar)
• Max. dierential (Pstop-Pstart) 7,5 bar (version plus=11,5 bar)
• Minimum dierential (Pstop-Pstart)) SW: 0,5 ba
SW2 synchro: 1 bar
• Factory setting (start/stop) 3/4 bar
• Hydraulic inlet G1/4” Female - NPT 1/4” Fem.
• Net weight (without cables) 0,3 kg
HYDRAULIC INSTALLATION (diagram A)
SWITCHMATIC equipment must be threaded to a tting G1/4” male
at the pump´s outlet.
Before connecting the SWITCHMATIC verify that the hydraulic system is
properly installed, especially if the hydropneumatic tank is pressurized.
ELECTRIC CONNECTION (diagram B)
The electric connection must be performed by qualied personal in
compliance with regulation of each country. Before doing manipulations
inside the device, it must be disconnected from the electric supply.
Wrong connection could spoil the electronic circuit.
The manufacturer declines all responsability in damages caused by
wrong connections.
When carrying out the electrical connection it is compulsory to use a dieren-
tial switch of high sensitivity: I = 30 mA (clase A o AC). It is compulsory to use a
magnetothermic switch adapted at the motor load.
Check if power supply is between 115-230V (SW1-2).
If you have purchased the unit without cables follow diagram B:
• Use cables type H07RN-F 3G1 or 3G1,5 with section enough to the power
installed.
• Do the pump connection U, V and
(SW1-2) o 1, 2 y al cuadro (Only
SW3)
• Do the power supply connection L1, N and .
• The earth conductor must be longer than the others. It will be the rst
one to be mounted during the assembly and the last one to be discon-
nected during the dismantling. The earth conductors connections are
compulsory!
• (Only version A) The device has a volt-free contact for monitoring the alarms
displayed in the screen originated by irregularities or problems of the system.
For the connection see Diagram C.
CONTROL PANEL (diagram C)
The meanings of the dierent control panel elements are summarized on the
following tables, where:
• O means lit LED light.
• ( ( O ) ) means slow-ashing.
• (((O))) means fast-ashing.
DISPLAY ACTION
OPERATION MODE
Is showed on screen instantaneous pressure or instanta-
neous current consumption
ADJUSTMENT MODE
Is displayed on screen the adjusted start pressure
blinking.
Is displayed on screen the adjusted stop pressure blin-
king.
Is displayed the adjusted rated current blinking (only
SW2).
ALARM MODE Is displayed the alarm code
STAND-BY MODE Are displayed 3 ashing dots
BASIC CONFIGURA-
TION MODE
Is displayed the sequence of basic conguration para-
meters
ADVANCED CONFI-
GURATION MODE
Is displayed the sequence of advanced conguration
parameters
LEDS STATE MEANING
bar
O It indicates the instantaneous pressure in bar
( ( O ) )
It indicates the instantaneous pressure in bar +
pump operating (only SW1/SW3)
psi
O It indicates the instantaneous pressure in psi
( ( O ) )
It indicates the instantaneous pressure in psi +
pump operating (only SW1/SW3)
A
(only SW2)
O
It indicates the instantaneous current consumption
in Ampere units
( ( O ) ) Pump ON
START
O Is displayed the start pressure
( ( O ) ) Adjusting start pressure
STOP
O Is displayed the stop pressure
( ( O ) ) Adjusting stop pressure
O Ratied dry-running or overload alarms
( ( O ) )
Dry-running alarm performing ART or overload
alarm preforming any of the 4 restore attempts
(((O))) Fast-cycling alarm
